Suzuki GS 400 (1976-77) technical specifications
Suzuki GS 400 is produced in 1976-77. Engine is Four stroke, parallel twin cylinders, DOHC, 2 valve per cylinder., displacement 398 cc / 24.2 cu-in , produces power 25.4 kW / 34 hp / @ 8000 rpm and 30 Nm / 2.94 kpm / 22.1 lb-ft @ 7000 rpm. Suzuki GS 400 weighs 172 kg / 378 lbs. Suzuki GS 400 has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | GS 400 |
| Years: | 1976-77 |
| Engine: | Four stroke, parallel twin cylinders, DOHC, 2 valve per cylinder. |
| Capacity: | 398 cc / 24.2 cu-in |
| Bore x Stroke: | 65 x 60 mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 9:1 |
| Induction: | 2 x Mikuni BS34 carburetors |
| Ignition: | Conventional type non-transistor |
| Starting: | Electric and kick-start. |
| Max Power: | 25.4 kW / 34 hp / @ 8000 rpm |
| Max Torque: | 30 Nm / 2.94 kpm / 22.1 lb-ft @ 7000 rpm |
| Clutch: | Wet multi-plate type |
| Transmission: | 6 Speed |
| Final Drive: | Chain |
| Primary Drive Ratio: | 2.714 |
| Final Drive Ratio: | 2.461 |
| Gear Ratio: | 1st 2.461 / 2nd 1.777 / 3rd 1.380 / 4th 1.125 / 5th 0.961 / 6th 0.851:1 |
| Frame: | Double cradle tube |
| Front Suspension: | Telescopic, coil spring, oil damped |
| Rear Suspension: | Swing arm, coil spring (5-way adjustable), oil damped |
| Front Brakes: | Single 270 mm disc, 1 piston caliper |
| Rear Brakes: | 160 mm Drum |
| Front Tyre: | 3.00-18 |
| Rear Tyre: | 3.50-18 |
| Dimensions: | Length 2085 mm / 82.1 in Width 840 mm / 33.1 in |
| Wheelbase: | 1385 mm / 54.5 in |
| Seat Height: | 790 mm / 31.1 in |
| Ground Clearance: | 170 mm / 6.7 in |
| Dry Weight: | 172 kg / 378 lbs |
| Wet Weight: | 185.0 kg / 408 lbs |
| Fuel Capacity: | 14 Litres / 3.7 US gal / 3.1 Imp gal |
