Technical specifications
|
| Model: |
DR-Z 250 |
| Years: |
2001-04 |
|
Engine:
|
Four stroke, single cylinder, DOHC, 4 valves, TSCC
|
|
Capacity:
|
249 cc / 15.2 cu in
|
|
Bore x Stroke:
|
73. x 59.6 mm
|
|
Compression Ratio:
|
10.4:1
|
|
Cooling System:
|
Air/oil cooled
|
|
Lubrication System:
|
Wet sump
|
|
Induction:
|
Mikuni TM28SS carburetor or 32 mm carburetor in Calafornia
|
|
Battery:
|
12V, 4Ah
|
|
Starting:
|
Electric / Kick
|
|
Ignition:
|
Digital CDI
|
|
Clutch:
|
Mulit-plate
|
|
Transmission:
|
6 Speed, constant mesh
|
|
Final Drive:
|
Chain
|
|
Front Suspension:
|
43 mm Showa telescopic, oil-damped, 12-way adjustable compression and 17-way rebound damping
|
|
Front Wheel Travel:
|
280 mm / 11 in
|
|
Rear Suspension:
|
Link-type, gas/oil-damped, fully-adjustable compression/rebound damping and preload, Showa
|
|
Rear Wheel Travel:
|
280 mm / 11 in
|
|
Front Brakes:
|
Single disc, 250 mm
|
|
Rear Brakes:
|
Single disc, 220 mm
|
|
Front Tyre:
|
80/100-21
|
|
Rear Tyre:
|
100/100-18
|
|
Rake:
|
26.5o
|
|
Trail:
|
108 mm / 4.3 in
|
|
Dimensions:
|
Length: 2150 mm / 84.6 in Width: 880 mm / 34.6 in Height: 1215 mm / 47.8 in
|
|
Wheelbase:
|
1455 mm / 57.3 in
|
|
Ground Clearance:
|
300 mm / 11.8 in
|
|
Seat Height:
|
900 mm / 35.4 in
|
|
Dry Weight:
|
115 kg / 254 lbs
|
|
Fuel Capacity:
|
10.5 L / 2.8 US gal / 2.3 Imp gal
|
