Technical specifications
|
| Model: |
DL 650 V-Strom XP |
| Years: |
2009-10 |
|
Engine:
|
Four stroke, 90°-V-twin, DOHC, 4 valves per cylinder.
|
|
Capacity:
|
645 cc / 39.4 cu-in
|
|
Bore x Stroke:
|
81 x 62.6 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
11.5:1
|
|
Lubrication:
|
Wet sump
|
|
Induction:
|
Fuel Injection 39 mm
|
|
Ignition:
|
Electronic Ignition
|
|
Spark Plug:
|
NGK, CR8E
|
|
Starting:
|
Electric
|
|
Max Power:
|
49 kW / 66.6 hp @ 8800 rpm
|
|
Max Torque:
|
63.1 Nm / 6.4 kgf-m / 45.5 lb-ft @ 7600 rpm
|
|
Clutch:
|
Wet, multiple discs, cable operated
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain
|
|
Frame:
|
Aluminium, twin spar
|
|
Front Suspension:
|
Telescopic, coil spring, oil damped, spring preload adjustable
|
|
Front Wheel Travel:
|
160 mm / 6.2 in
|
|
Rear Suspension:
|
Link type, oil damped, coil spring, spring preload fully adjustable, rebound damping force fully adjustable
|
|
Rear Wheel Travel:
|
163 mm / 6.4 in
|
|
Front Brakes:
|
2 x 310 mm disc, 2 piston calipers, ABS
|
|
Rear Brakes:
|
Single 260 mm disc, 1 piston caliper, ABS
|
|
Front Tyre:
|
110/80R19
|
|
Rear Tyre:
|
150/70R17
|
|
Dimensions:
|
Length 2290 mm / 90.1 in Width 840 mm / 33.0 in Height 1390 mm / 54.7 in
|
|
Wheelbase:
|
1555 mm / 61.2 in
|
|
Seat Height:
|
820 mm / 32.3 in
|
|
Ground Clearance:
|
165 mm / 6.4 in
|
|
Dry Weight:
|
194 kg / 427.6 lbs
|
|
Wet Weight:
|
220 kg / 485 lbs
|
|
Fuel Capacity:
|
22 Litres / 5.8 US gal / 4.8 Imp gal
|
|
Standing ¼ Mile:
|
13.2 sec
|
|
Top Speed:
|
180 km/h / 112 mph
|
