Suzuki AN 125 Burgman (2002-06) technical specifications
Suzuki AN 125 Burgman is produced in 2002-06. Engine is Four stroke, single cylinder, 4 valves, displacement 124 cc / 7.6 cu in , produces power 9.2 kW / 12.4 hp @ 8500 rpm and 11 Nm / 1.1 kgf-m / 8.1 lb-ft @ 7000 rpm. Suzuki AN 125 Burgman weighs 139 kg / 306 lbs. Suzuki AN 125 Burgman has 2 photos.
Technical specifications
+ Add to 'Compare list'| Model: | AN 125 Burgman |
| Years: | 2002-06 |
| Engine: | Four stroke, single cylinder, 4 valves |
| Capacity: | 124 cc / 7.6 cu in |
| Bore x Stroke: | 57 x 48.8 mm |
| Compression Ratio: | 11.6:1 |
| Cooling System: | Liquid cooled |
| Induction: | Electronic injection, Keihin CVK24 |
| Ignition: | CDI |
| Starting: | Electric |
| Max Power: | 9.2 kW / 12.4 hp @ 8500 rpm |
| Max Torque: | 11 Nm / 1.1 kgf-m / 8.1 lb-ft @ 7000 rpm |
| Transmission: | Variable ratio, automatic |
| Final Drive: | V-belt |
| Front Suspension: | Telescopic with coil spring, oil damped |
| Rear Suspension: | Swingarm, oil damped, coil spring, preload adjustable |
| Rake: | 26.7º |
| Trail: | 97 mm / 3.8" |
| Front Brakes: | Single 240 mm disc, 2 piston caliper |
| Rear Brakes: | Single 220 mm disc, 1 piston caliper |
| Front Tyre: | 110/90-12 |
| Rear Tyre: | 130/70-12 |
| Dimensions: | Length: 2085 mm / 82.1" Width: 720 mm / 28.3" Height: 1325 mm / 52.2" |
| Wheelbase: | 1450 mm / 57.1" |
| Ground Clearance: | 127 mm / 5.0" |
| Seat Height: | 705 mm / 27.8" |
| Dry Weight: | 139 kg / 306 lbs |
| Fuel Capacity: | 10 Litres / 2.6 US gal |
