Technical specifications
|
| Model: |
Zip 50 2T |
| Years: |
2014 |
|
Engine:
|
Two stroke, single cylinder, Hi-PER2
|
|
Capacity:
|
49.4 cc / 3.0 cub in.
|
|
Bore x Stroke:
|
39 mm x 41.8 mm
|
|
Cooling System:
|
Forced air cooled
|
|
Lubrication:
|
Automatic mixer controlled by engine speed
|
|
Fuel System:
|
Carburetor
|
|
Ignition:
|
Electronic
|
|
Starting:
|
Electric / kick
|
|
Max Power:
|
3.3 kW / 4.5 hp @ 6700 rpm
|
|
Max Torque:
|
4.3 Nm / 0.44 kgf-m / 3.17 lb-ft @ 6500 rpm
|
|
Transmission:
|
CVT, with torque server
|
|
Clutch:
|
Automatic centrifugal dry clutch
|
|
Frame:
|
Single cradle, high strength tubular steel
|
|
Front Suspension:
|
Hydraulic telescopic fork
|
|
Front Wheel Travel:
|
75 mm / 3.0 in.
|
|
Rear Suspension:
|
Hydraulic single shock absorber
|
|
Rear Wheel travel:
|
74 mm / 2.9 in.
|
|
Front Brakes:
|
175 mm disc
|
|
Rear Brakes:
|
110 mm drum
|
|
Front Tyre:
|
100/80 - 10 in.
|
|
Rear Tyre:
|
120/70 - 10 in.
|
|
Dimensions:
|
Length: 1700 mm / 66.9 in. Width: 680 mm / 26.8 in.
|
|
Wheelbase:
|
1200 mm / 47.2 in.
|
|
Seat Height:
|
Adjustable 750 - 780 mm / 29.5 - 30.7 in.
|
|
Dry Weight:
|
89 kg / 196 lbs
|
|
Fuel Capacity:
|
7.3 L / 1.9 US gal
|
|
Consumption Average:
|
2.3 L/100 km / 44 km/l / 103 US mpg
|
|
Colours:
|
Midnight blu, Nero Lucido, Bianco Ottico
|
|
