Piaggio Liberty 125 3V (2014) technical specifications
Piaggio Liberty 125 3V is produced in 2014. Engine is Four stroke, single cylinder, SOHC, 3 valve, displacement 124 cc / 7.6 cub in. , produces power 7.6 kW / 10.3 hp @ 7500 rpm and 10.4 Nm / 1.06 kgf-m / 7.67 lb-ft @ 6000 rpm. Piaggio Liberty 125 3V top speed is 95 km/h / 59 mph. Piaggio Liberty 125 3V has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Liberty 125 3V |
| Years: | 2014 |
| Engine: | Four stroke, single cylinder, SOHC, 3 valve |
| Capacity: | 124 cc / 7.6 cub in. |
| Bore x Stroke: | 52 x 58.6 mm |
| Cooling System: | Forced air |
| Lubrication: | Wet sump |
| Fuel System: | Injection |
| Starting: | Electric, with flywheel |
| Max Power: | 7.6 kW / 10.3 hp @ 7500 rpm |
| Max Torque: | 10.4 Nm / 1.06 kgf-m / 7.67 lb-ft @ 6000 rpm |
| Clutch: | Automatic centrifugal dry clutch |
| Transmission: | CVT with torque server |
| Final Drive: | Belt |
| Frame: | High strength tubular steel single cradle frame |
| Front Suspension: | Hydraulic telescopic fork |
| Rear Suspension: | Hydraulic shock absorber with adjustable preload |
| Front Brakes: | 240 mm Disc with hydraulic controls |
| Rear Brakes: | 140 mm Drum |
| Front Tyre: | 80/90 - 15 |
| Rear Tyre: | 100/80 - 14 |
| Dimensions: | Length: 1920 mm / 75.5 in. Width: 700 mm / 27.6 in. |
| Wheelbase: | 1345 mm / 53.0 in. |
| Seat Height: | 790 mm / 31.1 in. |
| Fuel Capacity: | 6.5 L / 1.7 US gal |
| Consumption average: | 3.3 L/100 km / 30.3 km/L / 71 mpg |
| Top Speed: | 95 km/h / 59 mph |
| Colours: | Bianco Perla, Blu Midnight, Nero Grafite, Marrone Onix |
