Norton V4CR Café Racer (2023) technical specifications

Norton V4CR Café Racer is produced in 2023. Engine is Four stroke, 72 ° V-four cylinder, chain-driven cams with idler gear for reduced engine height. Titanium inlet valves., displacement 1200 cc / 73.2 cu-in , produces power 185 hp / 136 kW @ 12500 rpm and 125 Nm / 92.1 ft-lb @ 9000 rpm. Norton V4CR Café Racer weighs 193 kg / 425.4 lbs. Norton V4CR Café Racer has 7 photos.

Technical specifications

+ Add to 'Compare list'

Model:	V4CR Café Racer
Years:	2023
Engine:	Four stroke, 72 ° V-four cylinder, chain-driven cams with idler gear for reduced engine height. Titanium inlet valves.
Capacity:	1200 cc / 73.2 cu-in
Bore x Stroke:	82 x 56.8 mm
Compression Ratio:	13.6:1
Cooling System:	Liquid-cooled
Induction:	Electronic fuel-injection system, 8-fuel injectors. Full drive-by-wire system independent on front and rear banks of cylinders for ultimate control and feel
Electronic Aids:	Linked to rider-mode: Lean-angle sensitive Traction-control using six-axis Inertial Measurement Unit (IMU). Front and rear ABS. Wheelie control.
Ignition:	Keyless ignition system with electronic steering lock
Starting:	Electric
Max Power:	185 hp / 136 kW @ 12500 rpm
Max Torque:	125 Nm / 92.1 ft-lb @ 9000 rpm
Transmission:	Full quickshift system and auto down blipper
Final Drive:	Chain
Chassis:	Aluminium tubular chassis. Aerospace 5-axis CNC machined outriggers and headstock. Frame is hand TIG welded at Norton HQ and hand-polished to a mirror finish
Swingarm:	Braced and underslung single-sided billet swingarm with rising rate linkage geometry developed from the TT race bikes
Front Suspension:	43mm Öhlins NIX30 system front fork. Fully adjustable
Rear Suspension:	Öhlins TTXGP Norton bespoke fully adjustable rear shock
Front Brakes:	2 x 330mm floating discs. Radially mounted Brembo monobloc calipers. Brembo discs, and Brembo master cylinder
Rear Brakes:	Single 245mm rear disc. Brembo caliper and master-cylinder
Wheels:	Carbon model: Carbon fibre BSTs Manx model: Oz racing forged aluminium
Headstock Angle:	23.5°
Wheelbase:	1435 mm / 56.4 in
Wet Weight:	204 kg / 436 lbs
Dry Weight:	193 kg / 425.4 lbs
Fuel Capacity:	15 Litres / 3.9 US gal
