Norton Atlas Nomad (2019) technical specifications

Norton Atlas Nomad is produced in 2019. Engine is Four stroke, parallel twin. 270 degree firing order. Chain driven DOHC, with idler gear., displacement 650 cc / 39.6 cu-in , produces power 84 hp / 62.6 kW @ 11000rpm and 64 Nm / 47.9 lb-ft. Norton Atlas Nomad weighs 178 kg / 392.4 lbs. Norton Atlas Nomad has 6 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Atlas Nomad
Years:	2019
Engine:	Four stroke, parallel twin. 270 degree firing order. Chain driven DOHC, with idler gear.
Capacity:	650 cc / 39.6 cu-in
Bore x Stroke:	82 x 61.5mm
Compression Ratio:	11.5:1
Cooling System:	Liquid cooled
Emission:	Euro 4, Full compliance including secondary air injection and EVAP.
Induction:	Electronic fuel injection system. 4 fuel injectors. Full drive-by-wire system.
Lighting:	Full LED lighting system including super bright high and low beam, daytime running lights, rear lamp and indicators.
Starting:	Electric
Max Power:	84 hp / 62.6 kW @ 11000rpm
Max Torque:	64 Nm / 47.9 lb-ft
Transmission:
Final Drive:	Chain
Frame:	Twin tube seamless steel perimeter chassis with aluminium swingarm mount. Swingarm, Braced twin spar cast aluminium.
Front Suspension:	50mm diameter Roadholder USD forks. Preload, compression and rebound adjustable
Front Wheel Travel:	150 mm / 5.9 in
Rear Suspension:	Roadholder monoshock with rising rate linkage and piggyback reservoir. Adjustable preload.
Rear Wheel Travel:	150 mm / 5.9 in
Front Brakes:	2 x 320mm full floating Brembo discs. Radially mounted twin Brembo monoblock callipers with ABS. Brembo master cylinder.
Rear Brakes:	Single 245mm Brembo disc. Brembo twin piston rear calliper with ABS. Brembo master cylinder.
Front Wheel:	18 in spoke wheel with polished aluminium rim
Rear Wheel:	17 in spoke wheel with polished aluminium rim
Front Tyre:	110/80 R18 Avon Trekrider tyre
Rear Tyre:	180/55 R17 Avon Trekrider tyre
Headstock Angle:	24.2°
Wheelbase:	1446 mm / 56.9 in
Seat Height:	824 mm / 32.4 in
Dry Weight:	178 kg / 392.4 lbs
Fuel Capacity:	15 Litres / 3.9 US gal
