MV Agusta LXP Orioli (2024) technical specifications

MV Agusta LXP Orioli is produced in 2024. Engine is Four stroke, transverse three cylinder, DOHC with mechanical chain tensioner and DLC tappets, 4 valves per cylinder, displacement 931 cc / 96.8 cu-in , produces power 125 hp / 90.5 kW @ 10000 rpm and 102 Nm / 75 lb-ft @ 7000 rpm. MV Agusta LXP Orioli weighs 220 kg / 485 lbs. MV Agusta LXP Orioli has 6 photos.

Technical specifications

+ Add to 'Compare list'

Model:	LXP Orioli
Years:	2024
Production:	500 Units
Engine:	Four stroke, transverse three cylinder, DOHC with mechanical chain tensioner and DLC tappets, 4 valves per cylinder
Capacity:	931 cc / 96.8 cu-in
Bore x Stroke:	81 x 60.2 mm
Cooling System:	Cooling with separated liquid and oil radiators
Compression Ratio:	13.4:1
Engine Management System:	Integrated ignition ? injection system MVICS 2.1 (Motor & Vehicle Integrated Control System) with three injectors. Engine control unit Eldor Nemo EM 3.0 Throttle body with 47 mm diameter bore, full-ride-by wire Mikuni Pencil-coil with ion-sensing technology, control of detonation and misfire. Torque control with four maps. Traction Control with eight levels of intervention with lean angle sensor and inertial measurement unit (IMU)
Emission:	Euro 5
Starting:	Electric
Max Power:	125 hp / 90.5 kW @ 10000 rpm
Max Torque:	102 Nm / 75 lb-ft @ 7000 rpm
Clutch:	Wet multi-disc hydraulic clutch
Transmission:	Cassette style, six speed, constant mesh
Final Drive:	17/41
Primary Drive:	21/39
Gear Ratios:	1st = 13/40, 2nd = 16/35, 3rd = 18/30, 4th = 21/29, 5th = 23/28, 6th = 27/29
Frame:	Double beam frame structure, composed of high-tensile steel pipes and forged components. Bolt on double cradle and rear from Trellis structure, composed of high-tensile steel pipes and forged components
Front Suspension:	48 mm Sachs ?UPSIDE DOWN? telescopic hydraulic fork with rebound ? compression damping and spring preload external and separate adjustment.
Front Wheel Travel:	210 mm / 8.3 in
Rear Suspension:	Progressive link, Sachs monoshock with rebound, compression and spring preload adjustable hydraulics.
Rear Wheel Travel:	210 mm / 8.3 in
Front Brakes:	2x 320mm floating disc with steel braking disc and flange Front brake radial-type monobloc Brembo Stylema 4-piston calipers
Rear Brakes:	Single 265mm disc with Brembo 2-piston caliper
ABS:	Continental MK100 with RLM (Rear Wheel Lift-up Mitigation) and cornering function.
Wheels:	Spoked
Front Wheel:	Tubeless, with aluminium hub and rim 2.15 x 21
Rear Wheel:	Tubeless, with aluminium hub and rim 4.00 x 18
Front Tyre:	90/90 ? 21M/C
Rear Tyre:	150/70 ? B18M/C
Trail:	118 mm / 4.6 in
Dimensions:	Length: 2360 mm / 92.9 in Width: 980 mm / 38.58 in
Wheelbase:	1610 mm / 63.4 in
Ground Clarence:	230 mm / 9.05 in
Seat Height:	850 - 870 mm / 33.46 - 34.25 in
Dry Weight:	220 kg / 485 lbs
Fuel Capacity:	20 Litres / 5.28 US gal
Electronics:	Full HD 7″ TFT Dash ? Bluetooth and Wi-Fi connectivity ? Cruise control ? Launch control ? 8 level Traction Control ? GPS sensor ? Immobilizer ? Full led headlight with DRL and bending function ? Full led tail light ? Fog light ? MV Ride app with turn by turn navigation system, engine and vehicle setup.
