MV Agusta F4RR (2012) technical specifications
MV Agusta F4RR is produced in 2012. Engine is Four stroke, transverse four cylinder. DOHC, radial valve, 4 radial valves per cylinder, displacement 998 cc / 60.9 cu-in , produces power 147,7 kW / 198 hp @ 13400 rpm and 114 Nm / 11.4 kgm @ 9200 rpm. MV Agusta F4RR weighs 192 Kg / 423 lbs. MV Agusta F4RR has 6 photos.
Technical specifications
+ Add to 'Compare list'Model: | F4RR |
Years: | 2012 |
Engine: | Four stroke, transverse four cylinder. DOHC, radial valve, 4 radial valves per cylinder |
Capacity: | 998 cc / 60.9 cu-in |
Bore x Stroke: | 78 x 50.9 mm |
Compression Ratio: | 13.4:1 |
Cooling System: | Cooling with separated liquid and oil radiators |
Engine Management: | Magneti Marelli IAW 7BM ignition – injection integrated system with Mikuni throttle body; induction discharge electronic ignition; Sequential timed “Multipoint” electronic injection ; Variable height intake ducts with Torque Shift System (TSS) |
Alternator: | 350 W at 5000 r.p.m. |
Battery: | 12 V - 8.6 Ah |
Starting: | Electric |
Max Power: | 147,7 kW / 198 hp @ 13400 rpm |
Max Torque: | 114 Nm / 11.4 kgm @ 9200 rpm |
Clutch: | Wet, multi – disc with mechanical anti-surging device and BREMBO radial master cylinder |
Transmission: | 6 Speed |
Final Drive: | Chain |
Gear Ratio: | 1st Speed* 14/37 134.1 km/h 83.3 mph @ 13700 rpm 2nd Speed* 16/33 171.8 km/h 106.7 mph @ 13700 rpm 3rd Speed* 18/31 205.8 km/h 127.8 mph @ 13700 rpm 4th Speed* 20/30 236.3 km/h 146.7 mph @ 13700 rpm 5th Speed* 22/29 268.9 km/h 167.0 mph @ 13700 rpm 6th Speed* 21/25 297.6 km/h 184.8 mph @ 13700 rpm |
Frame: | CrMo Steel tubular trellis (TIG welded) Rear swing arm pivot plates: material Aluminium alloy - Adjustable swingarm pivot height |
Front Suspension: | 43mm “UPSIDE - DOWN” ÖHLINS telescopic hydraulic fork with rebound-compression damping and spring preload external and separate adjustment |
Front Wheel Travel: | 120 mm / 4.3 in |
Rear Suspension: | ÖHLINS TTX Progressive, single shock absorber with rebound and compression damping and spring preload adjustment Single sided swing arm: material Aluminium alloy |
Rear Wheel Travel: | 120 mm / 4.3 in |
Front Brakes: | 2x 320mm discs 4 piston calipers |
Rear Brakes: | Single 210mm disc 4 piston caliper |
Rim Front: | Forged aluminium alloy 3.50 " x 17 " |
Rim Rear: | Forged aluminium alloy 6.00 " x 17 " |
Front Tyre: | 120/70 -ZR 17 |
Rear Tyre: | 190/55 -ZR 17 |
Trail: | 100,4 mm / 3.9 in |
Dimensions: | Length 2100 mm / 82.6 in Width 750 mm / 29.5 in |
Wheelbase: | 1430 mm / 56.2 in |
Seat Height: | 830 mm / 32.66 in |
Ground Clearance: | 115 mm / 4.52 in. |
Dry Weight: | 192 Kg / 423 lbs |
Fuel Capacity: | 17 Litres / 4.49 US gal |
