MV Agusta F4 1000S (2005-06) technical specifications

MV Agusta F4 1000S is produced in 2005-06. Engine is Four stroke, transverse four cylinder. DOHC, 4 valves per cylinder, displacement 998 cc / 60.9 cu-in , produces power 122 kW / 166 hp @ 11750 rpm and 109 Nm / 11.1 kgf-m @ 10200 rpm. MV Agusta F4 1000S top speed is 297.6 km/h / 184.3 mph. MV Agusta F4 1000S weighs 190 kg / 418.8 lbs. MV Agusta F4 1000S has 8 photos.

Technical specifications

+ Add to 'Compare list'

Model:	F4 1000S
Years:	2005-06
Engine:	Four stroke, transverse four cylinder. DOHC, 4 valves per cylinder
Capacity:	998 cc / 60.9 cu-in
Bore x Stroke:	76 x 55 mm
Cooling System:	Liquid cooled
Compression Ratio:	12.0:1
Induction:	Weber Marelli” 1.6 M ignition injection integrated system
Ignition:	Multipoint electronic injection
Starting:	Electric
Max Power:	122 kW / 166 hp @ 11750 rpm
Max Torque:	109 Nm / 11.1 kgf-m @ 10200 rpm
Clutch:	Wet, multiple discs, cable operated
Transmission:	6 Speed
Final Drive:	Chain
Frame:	Aluminium, Trellis frame
Front Suspension:	Inverted (USD) telescopic hydraulic fork with rebound-compression damping and spring preload adjustment, Titanium Nitride anti-friction treatment
Rear Suspension:	Progressive, single shock absorber with rebound and compression (High speed / Low speed) damping and spring preload (hydraulic control)
Front Brakes:	2x 310mm discs 6 piston calipers
Rear Brakes:	Single 210mm disc 4 piston caliper
Front Tyre:	120/65 ZR17
Rear Tyre:	180/55 ZR17
Trail:	104 mm / 4.1 in
Dimensions:	Length 2007 mm / 79.0 in Width 685 mm / 26.9 in
Wheelbase:	1408 mm / 55.4 in
Dry Weight:	190 kg / 418.8 lbs
Fuel Capacity:	21 Litres / 5.5 US gal
Consumption Average:	14.3 km/lit
Standing ¼ Mile:	10.5 sec
Top Speed:	297.6 km/h / 184.3 mph
