MV Agusta Brutale 675 (2014) technical specifications
MV Agusta Brutale 675 is produced in 2014. Engine is Four stroke, transverse three cylinder. DOHC, 4 Valve per cylinder, displacement 675 cc / 41.2 cu-in , produces power 84.5 kW / 113 hp @ 12500 rpm and 71 Nm / 7.24 kg-m @ 10600 rpm. MV Agusta Brutale 675 weighs 163 kg / 358 lbs. MV Agusta Brutale 675 has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Brutale 675 |
| Years: | 2014 |
| Engine: | Four stroke, transverse three cylinder. DOHC, 4 Valve per cylinder |
| Capacity: | 675 cc / 41.2 cu-in |
| Bore x Stroke: | 79 x 45.9 mm |
| Cooling System: | Liquid cooled |
| Compression Ratio: | 12.0:1 |
| Induction: | Integrated ignition - injection system with three injectors Engine control unit Eldor EM2.0, throttle body full drive by wire Mikuni, pencil-coil with ion-sensing technology, control of detonation and misfire Torque control with four maps, Traction Control with eight levels of intervention |
| Ignition: | Digital CDI |
| Voltage: | 12 V |
| Alternator: | 350 W @ 5000 rpm |
| Battery: | 12 V - 8.6 Ah |
| Starting: | Electric |
| Max Power: | 84.5 kW / 113 hp @ 12500 rpm |
| Max Torque: | 71 Nm / 7.24 kg-m @ 10600 rpm |
| Clutch: | Wet, multiple discs, cable operated |
| Transmission: | 6 Speed |
| Final Drive: | Chain |
| Gear Ratio: | 1st : 1/14.493 2nd: 1/10.821 3rd: 1/9.053 4th: 1/8.040 5th: 1/7.274 6th: 1/6.712 |
| Final Drive Ratio: | 16/43 |
| Frame: | ALS Steel tubular trellis, Rear swing arm pivot plates: material Aluminium alloy |
| Front Suspension: | 43mm“UPSIDE - telescopic hydraulic fork, |
| Front Wheel Traval: | 125 mm / 4.9 in |
| Rear Suspension: | Progressive, single shock absorber with spring preload adjustment |
| Rear Wheel Travel: | 123 mm / 4.8 in |
| Front Brakes: | 2x 320mm floating discs 4 pistons calipers |
| Rear Brakes: | Single 220mm disc single piston caliper |
| Front Tyre: | 120/70-ZR17 |
| Rear Tyre: | 180/55-ZR17 |
| Trail: | 95 mm / 3.74 in. |
| Dimensions: | Length 2085 mm / 82.0 in Width 725 mm / 28.5 in |
| Wheelbase: | 1380 mm / 54.3 in |
| Seat Height: | 812 mm / 31.9 in |
| Ground Clearance: | 149 mm / 5.8 in |
| Dry Weight: | 163 kg / 358 lbs |
| Fuel Capacity: | 17.5 Litres / 4.6 US gal |
