MV Agusta 98 Turismo (1945-48) technical specifications

MV Agusta 98 Turismo technical specifications

MV Agusta 98 Turismo is produced in 1945-48. Engine is Two stroke, single cylinder, displacement 98 cc / 5.9 cu-in , produces power 2.6 kW / 3.5 hp @ 4500 rpm. MV Agusta 98 Turismo has 2 photos.

Technical specifications

+ Add to 'Compare list'
Model: 98 Turismo
Years: 1945-48
Units Produced: approx. 1700
Engine: Two stroke, single cylinder
Capacity: 98 cc / 5.9 cu-in
Bore x Stroke: 48 x 54 mm
Cooling System: Air cooled
Compression Ratio: 6.0:1
Induction: 16 mm Carburettor
Lubrication: 8% mixture
Ignition: Flywheel magneto
Starting: Kick
Max Power: 2.6 kW / 3.5 hp @ 4500 rpm
Clutch: Wet multiple plate clutch
Transmission: 2 speeds (3 speed version from 1946)
Final Drive: Chain
Frame: Closed tubular steel cradle
Front Suspension: Girder forks (telescopic fork on Lusso)
Rear Suspension: Plunger-box
Front Brakes: 125mm Drum
Rear Brakes: 125mm Drum
Front Tyre: 2.50-19
Rear Tyre: 3.00x19
Dimensions: Length 1910 mm / 75.2 in Width 610 mm / 24.0 in
Wheelbase: 1250 mm / 49.2 in
Weight: 70 Kg / 154 lbs
Fuel Capacity: 9 Litres / 2.3 US gal
