MV Agusta 98 Turismo (1945-48) technical specifications
MV Agusta 98 Turismo is produced in 1945-48. Engine is Two stroke, single cylinder, displacement 98 cc / 5.9 cu-in , produces power 2.6 kW / 3.5 hp @ 4500 rpm. MV Agusta 98 Turismo has 2 photos.
Technical specifications
+ Add to 'Compare list'Model: | 98 Turismo |
Years: | 1945-48 |
Units Produced: | approx. 1700 |
Engine: | Two stroke, single cylinder |
Capacity: | 98 cc / 5.9 cu-in |
Bore x Stroke: | 48 x 54 mm |
Cooling System: | Air cooled |
Compression Ratio: | 6.0:1 |
Induction: | 16 mm Carburettor |
Lubrication: | 8% mixture |
Ignition: | Flywheel magneto |
Starting: | Kick |
Max Power: | 2.6 kW / 3.5 hp @ 4500 rpm |
Clutch: | Wet multiple plate clutch |
Transmission: | 2 speeds (3 speed version from 1946) |
Final Drive: | Chain |
Frame: | Closed tubular steel cradle |
Front Suspension: | Girder forks (telescopic fork on Lusso) |
Rear Suspension: | Plunger-box |
Front Brakes: | 125mm Drum |
Rear Brakes: | 125mm Drum |
Front Tyre: | 2.50-19 |
Rear Tyre: | 3.00x19 |
Dimensions: | Length 1910 mm / 75.2 in Width 610 mm / 24.0 in |
Wheelbase: | 1250 mm / 49.2 in |
Weight: | 70 Kg / 154 lbs |
Fuel Capacity: | 9 Litres / 2.3 US gal |
