Moto Guzzi V9 Bobber Special Edition (2023) technical specifications

Moto Guzzi V9 Bobber Special Edition technical specifications

Moto Guzzi V9 Bobber Special Edition is produced in 2023. Engine is Transversal 90° V-twin, 4-stroke, 2-valves per cylinder, displacement 853 cc / 52.0 cu-in , produces power 65 hp / 47.8 kW @ 6800 rpm and 73 Nm / 53.8 lb-ft @ 5000 rpm. Moto Guzzi V9 Bobber Special Edition weighs 194 kg / 427.6 lbs. Moto Guzzi V9 Bobber Special Edition has 6 photos.

Technical specifications

+ Add to 'Compare list'
Model: V9 Bobber Special Edition
Years: 2023
Engine: Transversal 90° V-twin, 4-stroke, 2-valves per cylinder
Capacity: 853 cc / 52.0 cu-in
Bore x Stroke: 84 x 77 mm
Cooling System: Air/oil cooled
Compression Ratio: 10.5:1
Exhaust: Stainless steel, 2-in-2 type, three-way catalytic converter with double lambda probe
Emission: Euro 5
Induction: Marelli MIU single-body electronic injection, integrated management of traction control on 2 levels
Ignition: Electronic
Starting: Electric
Max Power: 65 hp / 47.8 kW @ 6800 rpm
Max Torque: 73 Nm / 53.8 lb-ft @ 5000 rpm
Clutch: 170 mm Single disc with integrated flexible couplings
Transmission: 6 speeds (with overdrive top gear)
Final Drive: Double universal joint and double bevel gear units (8/33 ratio = 1: 4.125)
Gear Ratios: 1st 16/39 = 1: 2.437 2nd 18/32 = 1: 1.777 3rd 21/28 = 1: 1.333 4th 24/26 = 1: 1.083 5th 25/24 = 1: 0.96 6th 28/24 = 1: 0.857
Primary Drive: Helical teeth,ratio 21/25 = 1: 1.190
Frame: ALS steel twin tube cradle frame
Front Suspension: 40mm Standard fork
Front Wheel Travel: 130 mm / 5.1 in
Rear Suspension: Swingarm with double shock absorber with adjustable spring preload.
Rear Wheel Travel: 91 mm / 3.6 in
Front Brakes: Single 320 mm stainless steel floating disc, Brembo opposed four-piston callipers
Rear Brakes: Single 260 mm stainless steel floating disc, Brembo opposed two-piston callipers
Wheels: Aluminium alloy
Front Rim: 3.50 x 16
Rear Rim: 4.00 x 16
Front Tyre: 130/90 - 16
Rear Tyre: 150/80 B 16
Steering Head Angle: 38°
Rake: 26.4°
Trail: 117 mm / 4.6 in
Dimensions: Length: 2185 mm / 86.0 in Width: 840 mm / 33.0 in Height: 1120 mm / 44.0 in
Wheelbase: 1465 mm / 57.6 in
Seat Height: 785 mm / 30.9 in
Dry Weight: 194 kg / 427.6 lbs
Wet Weight: 210 kg / 462.9 lbs
Fuel Capacity: 15 Litres / 4.0 US gal
