Moto Guzzi V7 III Racer V7 III Racer 10th Anniversary (2020) technical specifications

Moto Guzzi V7 III Racer V7 III Racer 10th Anniversary technical specifications

Moto Guzzi V7 III Racer V7 III Racer 10th Anniversary is produced in 2020. Engine is Four stroke, 90° V twin, longitudinally mounted, OHV, 2 valves with light alloy pushrods and rockers, displacement 744 cc / 45.4 in , produces power 38 kW / 52 hp @ 6200 rpm and 60 Nm / 44.2 lb-ft @ 4900 rpm. Moto Guzzi V7 III Racer V7 III Racer 10th Anniversary weighs 193 kg / 425 lbs. Moto Guzzi V7 III Racer V7 III Racer 10th Anniversary has 4 photos.

Technical specifications

+ Add to 'Compare list'
Model: V7 III Racer V7 III Racer 10th Anniversary
Years: 2020
Engine: Four stroke, 90° V twin, longitudinally mounted, OHV, 2 valves with light alloy pushrods and rockers
Capacity: 744 cc / 45.4 in
Bore x Stroke: 80 x 74 mm
Cooling System: Air cooled
Compression Ratio: 9.6:1
Exhaust system: 3 way catalytic converter with twin oxygen sensor
Induction: Weber- Marelli electronic injection
Ignition: Magneti Marelli electronic digital
Battery: 12 V - 330 Watt Voltage 12 V - 14 Amph
Head Lamp: 12 V - 55/60 W
Starting: Electric
Max Power: 38 kW / 52 hp @ 6200 rpm
Max Torque: 60 Nm / 44.2 lb-ft @ 4900 rpm
Clutch: Single disc, dry, with cush drive
Transmission: 6 Speed
Final Drive: Shaft
Frame: Double cradle tubular frame. ALS steel. Detachable elements 1463 mm (57.6 inches)
Front Suspension: Marzocchi Ø 40 mm telescopic front forks
Front Wheel Travel: 120 mm / 4.7 in
Rear Suspension: Die-cast alloy swing arm with 2 shocks with adjustable spring preload Öhlins fully adjustable
Rear Wheel Travel: 96 mm / 3.8 in
Front Brakes: Single 320mm disc Brembo caliper with 4 differentiated and opposed pistons, ABS
Rear Brakes: Single 260mm disc 2 piston floating caliper, ABS
Front wheel: Spoked 18 in
Rear wheel: Spoked 17 in
Front Tyre: 100/90 -18 (110/80 R18 as alternative)
Rear Tyre: 130/80 - 17
Headstock Angle: 26.4°
Trail: 106 mm / 4.1 in
Dimensions: Length 2184 mm / 86 in Height 1110 mm / 43.7 in
Wheelbase: 1449 mm / 57.0 in
Seat Height: 770 mm / 30.3 in
Ground Clearance: 150 mm / 5.9 in
Dry Weight: 193 kg / 425 lbs
Wet Weight: 213 kg / 470 lbs
Fuel Capacity: 21 Litres / 5.5 US gal
Reserve: 3.7 Litres

Riders reviews(1)

daniel
2021.10.28 23:20
Appearance
5
Comfort
4
Performance
4
Durability
5
Maintcost
5
if your mechanical abilities are reasonable, costs will be low.
The v7,V711, V7111 are simple and mechanically accessible.
