Moto Guzzi V-7 750 Ambassador (1969-70) technical specifications
Moto Guzzi V-7 750 Ambassador is produced in 1969-70. Engine is Four stroke, 90° V twin, longitudinally mounted, OHV, 2 valve per cylinder, displacement 748.4 cc / 45.6 cu-in , produces power 62 hp / 46.2 kW @ 7250 rpm and NA. Moto Guzzi V-7 750 Ambassador weighs 227 kg / 500 lbs. Moto Guzzi V-7 750 Ambassador has 2 photos.
Technical specifications
+ Add to 'Compare list'Model: | V-7 750 Ambassador |
Years: | 1969-70 |
Engine: | Four stroke, 90° V twin, longitudinally mounted, OHV, 2 valve per cylinder |
Capacity: | 748.4 cc / 45.6 cu-in |
Bore x Stroke: | 83 x 70 mm |
Cooling System: | Air cooled |
Compression Ratio: | 9.8:1 |
Induction: | 2x 30mm Dell'Orto VHB 30CD carburetors |
Ignition: | Battery with double contact breaker with automatic advance |
Starting: | Electric |
Max Power: | 62 hp / 46.2 kW @ 7250 rpm |
Max Torque: | NA |
Transmission: | 5 Speed |
Final Drive: | Shaft |
Front Suspension: | Telehydraulic forks |
Rear Suspension: | Swinging arm with hydraulic dampers preload adjustable |
Front Brakes: | 2x 220mm drum |
Rear Brakes: | 220mm drum |
Front Tyre: | 90/90-18 |
Rear Tyre: | 110/90-18 |
Dry Weight: | 227 kg / 500 lbs |
Fuel Capacity: | 22.5 Litres / 5.9 US gal |
