Moto Guzzi Stelvio 1200 8V (2015-16) technical specifications
Moto Guzzi Stelvio 1200 8V is produced in 2015-16. Engine is Four stroke, 90° V twin, longitudinally mounted, OHV, 4 valve per cylinder., displacement 1151 cc / 70.2 cu-in , produces power 105 hp / 77 kW @ 7250 rpm and 113 Nm / 83.3 lb-ft @ 5800 rpm. Moto Guzzi Stelvio 1200 8V wet weight is 257 kg / 566 lbs. Moto Guzzi Stelvio 1200 8V has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Stelvio 1200 8V |
| Years: | 2015-16 |
| Engine: | Four stroke, 90° V twin, longitudinally mounted, OHV, 4 valve per cylinder. |
| Capacity: | 1151 cc / 70.2 cu-in |
| Bore x Stroke: | 95 x 81.2 mm |
| Cooling System: | Air cooled, |
| Compression Ratio: | 11.0:1 |
| Lubrication: | Wet sump |
| Induction: | Weber-Marelli electronic fuel injection with stepper motor control |
| Ignition: | Inductive discharge, digitally controlled, electronic twin spark ignition |
| Battery: | 12V - 18 Ah |
| Alternator: | 12 V - 550 W |
| Starting: | Electric |
| Exhaust: | stainless steel, 2-in-1 type, three-way catalytic converter with lambda probe |
| Max Power: | 105 hp / 77 kW @ 7250 rpm |
| Max Torque: | 113 Nm / 83.3 lb-ft @ 5800 rpm |
| Clutch: | Single plate with integrated flexible couplings |
| Transmission: | 6 Speed |
| Final Drive: | Shaft |
| Gear Ratio: | 1st 2.235 / 2nd 1.700 / 3rd 1.348 / 4th 1.1115 / 5th 0.968 / 6th 0.862 |
| Frame: | Tubular twin cradle, high tensile steel |
| Front Suspension: | Completely adjustable upside-down fork spring preload and hydraulic compression and rebound damping with mounting bracket for radial brake calliper, |
| Front Wheel Travel: | 170 mm / 6.69 in |
| Rear Suspension: | Single-sided swing-arm with progressive linkage and monoshock with adjustable hydraulic rebound and dial for setting spring preload |
| Rear Wheel Travel: | 155 mm / 6.10 in |
| Front Brakes: | 2x 320mm discs 4 piston caliper, ABS |
| Rear Brakes: | Single 282mm disc 2 piston caliper, ABS |
| Wheels: | Light alloy |
| Front wheel rim: | 2.50” x 19” |
| Rear wheel rim: | 4.25” x 17” |
| Front Tyre: | 110/80 ZR19 |
| Rear Tyre: | 180/55 ZR17 |
| Trail: | 125 mm / 4.92 in |
| Dimensions: | Length 2195 mm / 86.4 in Width 870 mm / 34.2 in Height 1125 mm / 44.2 in |
| Wheelbase: | 1535 mm / 60.4 in. |
| Seat Height: | 810 mm / 31.9 in (1.2 in / 30mm with lowered gel saddle available as an option) |
| Wet Weight: | 257 kg / 566 lbs |
| Fuel Capacity: | 23 Litres / 6.0 US gal |
