Moto Guzzi Nevada 750 Classic 20th Anniversary (2010) technical specifications
Moto Guzzi Nevada 750 Classic 20th Anniversary is produced in 2010. Engine is Four stroke, 90° V twin, longitudinally mounted, OHV, 2 valves per cylinder, displacement 744 cc / 45.4 cu-in , produces power 35.5 kW / 48 kW @ 6600 rpm and 54.7 Nm / 40.3 lb-ft @ 3600 rpm. Moto Guzzi Nevada 750 Classic 20th Anniversary weighs 184 kg / 405.7 lbs. Moto Guzzi Nevada 750 Classic 20th Anniversary has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Nevada 750 Classic 20th Anniversary |
| Years: | 2010 |
| Engine: | Four stroke, 90° V twin, longitudinally mounted, OHV, 2 valves per cylinder |
| Capacity: | 744 cc / 45.4 cu-in |
| Bore x Stroke: | 80 x 74 mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 9.6:1 |
| Lubrication: | By lobes with pressure pump |
| Exhaust: | Three-way catalyzer with Lambda sensor |
| Induction: | Weber-Marelli electric injection |
| Ignition: | Magneti Marelli electronic digital |
| Starting: | Electric |
| Max Power: | 35.5 kW / 48 kW @ 6600 rpm |
| Max Torque: | 54.7 Nm / 40.3 lb-ft @ 3600 rpm |
| Clutch: | Single disc, dry, with cush drive |
| Transmission: | 5 Speed |
| Final Drive: | Shaft |
| Gear Ratio: | 1st 11/26 = 1 : 2,3636 2nd 14/23 = 1 : 1,6429 3rd 18/23 = 1 : 1,2778 4th 18/19 = 1 : 1,0556 5th 25/22 = 1 : 0,88 |
| Frame: | Detachable tubular duplex cradle in special high-strengh steel |
| Front Suspension: | 40mm Marzocchi hydraulic telescopic fork |
| Front Wheel Travel: | 130 mm / 5.1 in |
| Rear Suspension: | Swinging fork in light alloy cast with two dampers and spring adjustable for preload and rebound |
| Rear Wheel Travel: | 130 mm / 5.1 in |
| Front Brakes: | Single 320mm disc 4 piston caliper |
| Rear Brakes: | Single 260mm disc 1 piston caliper |
| Front Tyre: | 100/90 V18 |
| Rear Tyre: | 130/90 V16 |
| Rake: | 27.5° |
| Trail: | 135 mm / 5.4 in |
| Dimensions: | Height 1068 mm / 42.0 in Length 2166 mm / 85.3 in Width 825 mm / 32.5 in |
| Wheelbase: | 1467 mm / 57.8 in |
| Seat Height: | 767 mm / 30.0 in |
| Ground clearance: | 190 mm / 7.5 in |
| Dry Weight: | 184 kg / 405.7 lbs |
| Fuel Capacity: | 14 Litres / 3.7 US gal |
