Moto Guzzi 850 Le Mans Mark I (1977) technical specifications

Moto Guzzi 850 Le Mans Mark I technical specifications

Moto Guzzi 850 Le Mans Mark I is produced in 1977. Engine is Four stroke, 90° V twin, longitudinally mounted, OHV pushrod, 2 valves per cylinder, displacement 844 cc / 51.5 cu-in , produces power 80 hp / 59.7 kW @ 7300 rpm and 79 Nm / 57.5 lb-ft @ 6000 rpm. Moto Guzzi 850 Le Mans Mark I top speed is 126 mph. Moto Guzzi 850 Le Mans Mark I weighs 198 kg / 435 lbs. Moto Guzzi 850 Le Mans Mark I has 4 photos.

Technical specifications

+ Add to 'Compare list'
Model: 850 Le Mans Mark I
Years: 1977
Engine: Four stroke, 90° V twin, longitudinally mounted, OHV pushrod, 2 valves per cylinder
Capacity: 844 cc / 51.5 cu-in
Bore x Stroke: 83 x 78 mm
Cooling System: Air cooled
Compression Ratio: 10.2:1
Lubrication: Gear driven oil pump with replaceable full flow oil filter
Induction: 2x 36mm Dell'Orto carburetors
Ignition: Battery with double contact breakers and coils
Starting: Electric
Max Power: 80 hp / 59.7 kW @ 7300 rpm
Max Torque: 79 Nm / 57.5 lb-ft @ 6000 rpm
Transmission: 5 Speed
Final Drive: Shaft
Frame: Duplex cradle
Front Suspension: Telescopic forks
Rear Suspension: Swinging arm, 5-WAY adjustable coil springs preload
Front Brakes: 2x 300mm discs
Rear Brakes: Single 242mm disc
Front Tyre: 3.5H-18
Rear Tyre: 4.10V-18
Wheelbase: 1470 mm / 57.9 in
Seat Height: 775 mm / 30.5 in
Ground Clearance: 184 mm / 7.2 in
Dry Weight: 198 kg / 435 lbs
Wet Weight: 232 kg / 512 lbs
Fuel Capacity: 22.5 Litres / 5.9 US gal
Consumption Average: 39.6 mpg
Top Speed: 126 mph
