Münch -4 TTS-E 1200 Mammut (1973-75) technical specifications

Münch -4 TTS-E 1200 Mammut is produced in 1973-75. Engine is Four stroke, traversed four cylinder, OHC, 2 valve per cylinder NSU car engine, displacement 1176 cc / 71.7 cu-in , produces power 100 hp. Münch -4 TTS-E 1200 Mammut top speed is 220 km/h / 137 mph. Münch -4 TTS-E 1200 Mammut wet weight is 292.0 kg / 656 lbs. Münch -4 TTS-E 1200 Mammut has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	-4 TTS-E 1200 Mammut
Years:	1973-75
Engine:	Four stroke, traversed four cylinder, OHC, 2 valve per cylinder NSU car engine
Capacity:	1176 cc / 71.7 cu-in
Bore x Stroke:	75.0 x 66.6 mm
Cooling System:	Air cooked
Compression Ratio:	9.8:1
Induction:	Einspritzer showing belt-driven Kugelfischer fuel injection pump with injectors fitted into manifold
Ignition:	Battery and coil, Bosch 400 watt, 6 volt generator
Max power:	100 hp
Clutch:	Wet multiplate clutch
Transmission:	4 Speed
Final Drive:	Enclosed-chain
Frame:	Twin loop cradle
Front Suspension:	Ko damper Telescopic forks
Rear Suspension:	Swinging arm, British Rickman or Italian Ceriani con panies, dual shocks
Front Brakes:	252mm Drum
Rear Brakes:	Drum
Front Tyre:	3.25-19
Rear Tyre:	4.00 -18
Wet Weight:	292.0 kg / 656 lbs
Fuel Capacity:	24 Litres / 6.3 US gal
Top Speed:	220 km/h / 137 mph
