Matchless G45 (1951-58) technical specifications

Matchless G45 is produced in 1951-58. Engine is Single cylinder, four stroke, OHV, displacement 498 cc / 30.4 cub in. Matchless G45 top speed is 210 km/h / 130 mph. Matchless G45 weighs 145 kg / 320 lbs. Matchless G45 has 5 photos.

Technical specifications

+ Add to 'Compare list'

Model:	G45
Years:	1951-58
Production:	Less than 100
Engine:	Single cylinder, four stroke, OHV
Capacity:	498 cc / 30.4 cub in.
Bore x Stroke:	66 x 72.8 mm
Cooling System:	Air cooled
Lubrication:	Dry sump
Oil Capacity:	4.0 L / 8.5 US pints
Exhaust:	Twin, chrome silencer
Fuel System:	Amal 930 concentric carburetors
Ignition:	Lucas competition magneto
Battery:	6V
Starting:	Kick
Clutch:	Dry, with primary belt drive
Transmission:	4-Speed, close ratio
Final Drive:	Chain
Maximum Power:	136.7 kW / 50 hp @ 7000 rpm
Frame:	Tubular cradle, tubular
Front Suspension:	AMC teledraulic, with stabilizer
Rear Suspension:	Dowty Oleomatic
Front Brakes:	Drum
Rear Brakes:	Drum
Wheels:	Steel, laced wire spokes
Front Tyre:	19 in
Rear Tyre:	19 in.
Dry Weight:	145 kg / 320 lbs
Top Speed:	210 km/h / 130 mph
