Technical specifications
|
| Model: |
Adventure 400 |
| Years: |
2016 |
|
Engine:
|
Four strike, single cylinder, SOHC, 4 valves
|
|
Capacity:
|
397 cc / 24.2 cu in
|
|
Cooling System:
|
Air cooled
|
|
Induction:
|
Siemens electronic fuel injection
|
|
Ignition:
|
Digital electronic
|
|
Starting:
|
Electric
|
|
Max Power:
|
20.1 kW / 27 hp @ 7000 rpm
|
|
Max Torque:
|
35 Nm / 3.57 kgf-m / 25.8 ft-lb @ 5500 rpm
|
|
Frame:
|
Tubular steel frame
|
|
Clutch:
|
Wet, multi-plate
|
|
Transmission:
|
5-Speed
|
|
Final Drive:
|
Chain
|
|
Front Suspension:
|
FAST ACE43 mm hydraulic fork, adjustable
|
|
Front Wheel Travel:
|
210 mm / 8.3 in
|
|
Rear Suspension:
|
Mono-shock, adjustable rebournd, compression and preload
|
|
Rear Wheel Travel:
|
200 mm / 7.9 in
|
|
Front Brakes:
|
Single 280 mm disc
|
|
Rear Brakes:
|
Single 220 mm disc
|
|
Front Tyre:
|
90/90-21
|
|
Rear Tyre:
|
130/80-18
|
|
Dimensions:
|
Length: 2140 mm / 84.3 in Width: 810 mm / 31.9 in Height: 1230 mm / 48.4 in
|
|
Seat Height:
|
880 mm / 34.6 in
|
|
Dry Weight:
|
151 kg / 333 lbs
|
|
Fuel Capacity:
|
19 Litres / 5.0 US gal / 4.2 Imp gal
|
