KTM RC8R 1190 (2013) technical specifications

KTM RC8R 1190 is produced in 2013. Engine is Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder, displacement 1195 cc / 73.0 cu-in , produces power 129 kW / 175 hp @ 10250 rpm and 127 Nm / 93.6 lb-ft @ 8000 rpm. KTM RC8R 1190 top speed is 271.4 km/h. KTM RC8R 1190 weighs 186.0 kg / 410.1 lbs. KTM RC8R 1190 has 5 photos.

Technical specifications

+ Add to 'Compare list'

Model:	RC8R 1190
Years:	2013
Engine:	Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder
Capacity:	1195 cc / 73.0 cu-in
Bore x Stroke:	105 x 69 mm
Cooling System:	Liquid cooling
Compression Ratio:	13.5 :1
Lubrication:	Pressure lubrication with 3 Eaton pumps
Induction:	Keihin EFI throttle body 52 mm
Ignition:	Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment
Staring:	Electric
Max Power:	129 kW / 175 hp @ 10250 rpm
Max Torque:	127 Nm / 93.6 lb-ft @ 8000 rpm
Clutch:	Wet, multiple discs, hydraulic operated
Transmission:	6 Speed claw shifted
Final Drive:	Chain 5/8 x 5/16" X Ring
Primary Gear Ratio:	40:76
Secondary Gear Ratio:	17:37
Frame:	Chromium-Molybdenum trellis frame, powder-coated Subframe Aluminium Handlebar Aluminium stump handlebar
Front Suspension:	43mm WP Upside down adjustable
Front Wheel Travel:	120 mm / 4.7 in
Rear Suspension:	WP shock, fully adjustable
Rear Wheel Travel:	125 mm / 4.9 in
Front Brakes:	2x 320mm discs 4 piston calipers
Rear Brakes:	Single 240mm disc
Front Tyre:	120/70 ZR17
Rear Tyre:	190/55 ZR17
Main silencer:	Stainless steel underfloor silencer with regulated catalytic converter
Steering Head Angle:	66.7°
Trail:	97 mm / 3.82 in
Wheelbase:	1425 mm / 56.1 in
Seat Height:	805 mm - 825 mm / 31.69in - 32.48in
Ground Clearance:	110 mm / 4.3 in
Dry Weight:	186.0 kg / 410.1 lbs
Fuel Capacity:	16.5 Litres / 4.3 gal
Standing ¼ Mile:	10.8 sec
Top Speed:	271.4 km/h
