Technical specifications
|
| Model: |
RC8 1190 |
| Years: |
2009 |
|
Engine:
|
Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder
|
|
Capacity:
|
1148 cc / 70.05 cu-un
|
|
Bore x Stroke:
|
103 x 69 mm
|
|
Cooling System:
|
Liquid cooling
|
|
Compression Ratio:
|
12.5 :1
|
|
Lubrication:
|
Pressure lubrication with 3 Eaton pumps
|
|
Exhaust:
|
Stainless steel underfloor silencer with regulated catalytic converter
|
|
Induction:
|
Electronic Injection. Keihin EFI with EPT (Electric Power Throttle)
|
|
Ignition:
|
Digital CDI
|
|
Starting:
|
Electric
|
|
Max Power:
|
113 kW / 152.2 hp @10000 rpm
|
|
Max Torque:
|
120.Nm / 12.2 kgf-m / 88.5 ft.lbs @ 8000 rpm
|
|
Clutch:
|
Wet multi-disc clutch, operated hydraulically
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain 5/8 x 5/16" X Ring
|
|
Frame:
|
Chromium-Molybdenum trellis frame, powder-coated. Subframe: Aluminium 7020.
|
|
Front Suspension:
|
43mm WP Upside down adjustable
|
|
Front Wheel Travel:
|
120 mm / 4.7 in
|
|
Rear Suspension:
|
WP shock, fully adjustable
|
|
Rear Wheel Travel:
|
125 mm / 4.9 in
|
|
Front Brakes:
|
2x 320mm discs 4 piston calipers
|
|
Rear Brakes:
|
Single 240mm disc
|
|
Front Tyre:
|
120/70 ZR17
|
|
Rear Tyre:
|
190/55 ZR17
|
|
Wheelbase:
|
1430 mm / 56.3 in
|
|
Seat Height:
|
805 mm / 31.7 in
|
|
Ground Clearance:
|
110 mm / 4.3 in
|
|
Dry Weight:
|
184.0 kg / 405.7 lbs
|
|
Fuel Capacity:
|
16.5 Litres / 3.5 gal
|
|
Road Test:
|
IN MOTO
|
