Technical specifications
|
| Model: |
RC 200 |
| Years: |
2017-18 |
|
Engine:
|
Four stroke, single cylinder. DOHC with finger followers, 4 Valve per cylinder,
|
|
Capacity:
|
199.5 cc / 12.1 cu-in
|
|
Bore x Stroke:
|
72 x 49 mm
|
|
Cooling System:
|
Liquid Cooled
|
|
Compression Ratio:
|
14.5:1
|
|
Induction:
|
Bosch Injection
|
|
Engine Lubrication:
|
Forced oil lubrication with 2 Eaton pumps
|
|
Ignition system:
|
Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment
|
|
Starting:
|
Electric
|
|
Max Power:
|
25.4 hp / 18.6 kW @ 10000 rpm
|
|
Max Torque:
|
14 lb-ft / 19.2 Nm @8000 rpm
|
|
Clutch:
|
Wet multi-disc clutch / mechanically operated
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain 5/8 x 1/4” X‑Ring
|
|
Primary Gear Ratio:
|
30:80
|
|
Secondary Gear Ratio:
|
15:45
|
|
Frame:
|
Tubular space frame made from steel, powder-coated
|
|
Front Suspension:
|
WP Suspension Up Side Down
|
|
Font Wheel Travel:
|
125 mm / 4.9 in
|
|
Rear Suspension:
|
WP Monoshock
|
|
Rear Wheel Travel:
|
150 mm / 5.9 in
|
|
Front Brakes:
|
Single 300 mmdisc
|
|
Rear Brakes:
|
Single 230 mm disc
|
|
Front Tyre:
|
95/75-R17
|
|
Rear Tyre:
|
115/75-R17
|
|
Rake:
|
65 °
|
|
Trail:
|
100 mm / 3.9 in
|
|
Seat Height:
|
820 mm / 32.3 in
|
|
Wheelbase:
|
1210 mm / 47.6 in
|
|
Ground Clearance:
|
179 mm / 7.0 in
|
|
Dry Weight:
|
137.0 kg / 303 lbs
|
|
Fuel Capacity:
|
10 Litres / 2.6 US gal
|
