Technical specifications
|
| Model: |
RC 125 |
| Years: |
2020-21 |
|
Engine:
|
Four stroke, single cylinder. DOHC with finger followers, 4 Valve
|
|
Capacity:
|
124.7 cc / 7.6 cu-in
|
|
Bore x Stroke:
|
58 x 47.2 mm
|
|
Cooling System:
|
Liquid Cooled
|
|
Compression Ratio:
|
14.5:1
|
|
Induction:
|
Bosch Injection
|
|
Lubrication:
|
Forced oil lubrication with 2 Eaton pumps
|
|
Ignition:
|
Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment
|
|
Starting:
|
Electric
|
|
Max Power:
|
15.hp / 10.9 kW @ 9500 rpm
|
|
Max Torque:
|
11.8 Nm / 8 lb•ft @ 8000 rpm
|
|
Clutch:
|
Wet multi-disc clutch / mechanically operated
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain 5/8 x 1/4” X‑Ring
|
|
Primary Gear Ratio:
|
30:80
|
|
Secondary Gear Ratio:
|
15:45
|
|
Frame:
|
Tubular space frame made from steel, powder-coated
|
|
Front Suspension:
|
WP Suspension Up Side Down
|
|
Font Wheel Travel:
|
120 mm / 4.7 in
|
|
Rear Suspension:
|
WP Monoshock
|
|
Rear Wheel Travel:
|
150 mm / 5.9 in
|
|
Front Brakes:
|
Single 300mm disc
|
|
Rear Brakes:
|
Single 230mm disc
|
|
Front Tyre:
|
110/70 -17
|
|
Rear Tyre:
|
150/60 –17
|
|
Rake:
|
65 °
|
|
Trail:
|
100 mm / 3.9 in
|
|
Seat Height:
|
820 mm / 32.3 in
|
|
Wheelbase:
|
1210 mm / 47.6 in
|
|
Ground Clearance:
|
179 mm / 7.0 in
|
|
Dry Weight:
|
135 kg / 297.6 lbs
|
|
Fuel Capacity:
|
10 Liters / 2.6 US gal
|
