KTM RC 125 (2016-17) technical specifications

KTM RC 125 is produced in 2016-17. Engine is Four stroke, single cylinder. DOHC with finger followers, 4 Valve, displacement 124.7 cc / 7.6 cu-in , produces power 15.hp / 10.9 kW @ 9500 rpm and 11.8 Nm / 8 lb•ft @ 8000 rpm. KTM RC 125 weighs 135 kg / 297.6 lbs. KTM RC 125 has 3 photos.

Technical specifications

+ Add to 'Compare list'

Model:	RC 125
Years:	2016-17
Engine:	Four stroke, single cylinder. DOHC with finger followers, 4 Valve
Capacity:	124.7 cc / 7.6 cu-in
Bore x Stroke:	58 x 47.2 mm
Cooling System:	Liquid Cooled
Compression Ratio:	14.5:1
Induction:	Bosch Injection
Lubrication:	Forced oil lubrication with 2 Eaton pumps
Ignition:	Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment
Starting:	Electric
Max Power:	15.hp / 10.9 kW @ 9500 rpm
Max Torque:	11.8 Nm / 8 lb•ft @ 8000 rpm
Clutch:	Wet multi-disc clutch / mechanically operated
Transmission:	6 Speed
Final Drive:	Chain 5/8 x 1/4” X‑Ring
Primary Gear Ratio:	30:80
Secondary Gear Ratio:	15:45
Frame:	Tubular space frame made from steel, powder-coated
Front Suspension:	WP Suspension Up Side Down
Font Wheel Travel:	120 mm / 4.7 in
Rear Suspension:	WP Monoshock
Rear Wheel Travel:	150 mm / 5.9 in
Front Brakes:	Single 300mm disc
Rear Brakes:	Single 230mm disc
Front Tyre:	110/70 -17
Rear Tyre:	150/60 –17
Rake:	65 °
Trail:	100 mm / 3.9 in
Seat Height:	820 mm / 32.3 in
Wheelbase:	1210 mm / 47.6 in
Ground Clearance:	179 mm / 7.0 in
Dry Weight:	135 kg / 297.6 lbs
Fuel Capacity:	10 Liters / 2.6 US gal
