KTM 950 Adventure s (2003-04) technical specifications

KTM 950 Adventure s is produced in 2003-04. Engine is Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder, displacement 942 cc / 57.4 cu-in , produces power 98 hp / 71.4 kW @ 8000 rpm and 95 Nm / 70.1 lb-ft @ 6500 rpm. KTM 950 Adventure s weighs 198 kg / 426.5 lbs. KTM 950 Adventure s has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	950 Adventure s
Years:	2003-04
Engine:	Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder
Capacity:	942 cc / 57.4 cu-in
Bore x Stroke:	100 x 60 mm
Cooling System:	Liquid cooling
Compression Ratio:	11.5;1
Lubrication:	Pressure lubrication with 2 Eaton pumps
Engine Oil:	Synthetic, 15w-50
Induction:	Constant-pressure carburetor Æ 43mm
Ignition:	Denso battery ignition
Spark Plug:	NGK, NGK CR 8 EK
Starting:	Electric
Max Power:	98 hp / 71.4 kW @ 8000 rpm
Max Torque:	95 Nm / 70.1 lb-ft @ 6500 rpm
Clutch:	Adventure - Silver/Black or Orange/Black / Adventure S - Orange/Black
Transmission:	6 Speed
Final Drive:	Chain, 17-42
Gear Ratio:	1st gear 35:12, 2nd gear 32:15, 3rd gear 30:18, 4th gear 27:20, 5th gear 27:2, 6th gear 26:27
Frame:	Chromium-molybdenum tubular space frame, powder-coated
Front Suspension:	WP-Upside-down 48 Multi Adjuster
Front Wheel Travel:	265 mm / 10.4 in
Rear Suspension:	WP - PDS with hydraulic spring preload
Rear Wheel Travel:	260 mm / 10.2 in
Front Brakes:	2x 300mm discs 2 piston calipers
Rear Brakes:	Single 240mm disc 2 piston caliper
Front Tyre:	90/90 -21
Rear Tyre:	150/70 -18
Rake:	26.6°
Trail:	119 mm / 4.7 in
Dimensions:	Height 950 mm / 37.4 in Width 950 mm / 37.4 in
Wheelbase:	1570 mm / 61.8 in
Seat Height:	915 mm / 36 in
Ground Clearance:	316 mm / 12.4 in
Dry Weight:	198 kg / 426.5 lbs
Fuel Capacity:	22 Litres / 5.8 US gal
