KTM 790 Duke The Scalpel (2019) technical specifications

KTM 790 Duke The Scalpel is produced in 2019. Engine is Four stroke, parallel twin cylinder, DOHC, 4 valve per cylinder, displacement 799 cc / 48.7 cu-in , produces power 78 kW / 105 hp @ 9000 rpm and 87 Nm / 63.4 lb-ft @ 8,000 rpm. KTM 790 Duke The Scalpel weighs 169 kg / 372.5 lbs. KTM 790 Duke The Scalpel has 6 photos.

Technical specifications

+ Add to 'Compare list'

Model:	790 Duke The Scalpel
Years:	2019
Engine:	Four stroke, parallel twin cylinder, DOHC, 4 valve per cylinder
Capacity:	799 cc / 48.7 cu-in
Bore x Stroke:	88 mm x 65.7 mm
Cooling System:	Liquid cooled
Compression Ratio:	12.7:1
Exhaust:	Stainless steel primary and secondary silencer
Lubrication:	Forced oil lubrication with 2 oil pumps
Induction:	DellOrto fuel-Injection
Ignition:	Bosch EMS with RBW
Starting:	Electric
Max Power:	78 kW / 105 hp @ 9000 rpm
Max Torque:	87 Nm / 63.4 lb-ft @ 8,000 rpm
Clutch:	PASC antihopping clutch, mechanically operated
Transmission:	6 Speed
Final Drive:	Chain 520 X-Ring
Primary Drive:	39:75
Secondary Gear Ratio:	16:41
Frame:	Chromium-Molybdenum-Steel frame using the engine as stressed element, powder coated
Front Suspension:	43mm WP upside-down
Front Wheel Travel:	140 mm / 5.5 in
Rear Suspension:	WP shock absorber with preload adjuster
Rear Wheel Travel:	150 mm / 5.9 in
Front Brakes:	2x 300mm discs
Rear Brakes:	Single 240mm disc
ABS:	Bosch 9MP two-channel ABS (incl. Supermoto mode, diesengageable)
Front Wheel:	3.50 x 17 in cast aluminium
Rear Wheel:	5.50 x 17 in cast aluminium
Front Tyre:	Maxxis Supermaxx ST 170/20Z R17
Rear Tyre:	Maxxis Supermaxx ST 182/20Z R17
Rake:	24°
Trail:	98 mm / 3.8 in
Steering Head Angle:	66°
Handlebar:	Aluminum, tapered, Ø 28/22 mm
Dimensions:	Length 2062 mm / 81.2 in Width 904 mm / 35.6 in Height 1059 mm / 41.7 in
Wheel base:	1475 ± 15 mm / 58 in
Seat Height:	825 mm / 32.4 in
Ground Clearance:	186 mm / 7.3 in
Dry Weight:	169 kg / 372.5 lbs
Fuel Capacity:	14 Litres / 3.7 US gal
