KTM 390 Duke (2019-20) technical specifications

KTM 390 Duke is produced in 2019-20. Engine is Four stroke, single cylinder. DOHC with finger followers, 4 valves, displacement 373 cc / 22.7 cu-in , produces power 43.5 hp / 32 kW @ 9500 rpm and 3.6 kg-m / 35.3 Nm @7000rpm. KTM 390 Duke weighs 149 kg / 328 lbs. KTM 390 Duke has 5 photos.

Technical specifications

+ Add to 'Compare list'

Model:	390 Duke
Years:	2019-20
Engine:	Four stroke, single cylinder. DOHC with finger followers, 4 valves
Capacity:	373 cc / 22.7 cu-in
Bore x Stroke:	89 x 60 mm
Cooling System:	Liquid Cooled
Compression Ratio:	12.6:1
Induction:	Bosch Injection
Lubrication:	Wet sump
Ignition:	Bosch EMS
Starting:	Electric
Max Power:	43.5 hp / 32 kW @ 9500 rpm
Max Torque:	3.6 kg-m / 35.3 Nm @7000rpm
Clutch:	PASC™ antihopping clutch, mechanically operated
Transmission:	6 Speed
Primary Drive Ratio:	30:80
Final Drive Ratio:	15:45
Final Drive:	Chain 5/8 x 1/4" X Ring
Frame:	Steel trellis frame, powder coated
Front Suspension:	WP inverted fork Ø 43 mm
Front Wheel Travel:	142 mm / 5.6 in
Rear Suspension:	WP monoshock
Rear Wheel Travel:	150 mm / 5.9 in
Front Brakes:	Single 320 mm disc, 4 piston radial caliper
Rear Brakes:	Single 230 mm disc 1 piston caliper
ABS:	Bosch 9MB two-channel ABS
Front Tyre:	110/70 -17
Rear Tyre:	150/60-17
Steering Head Angle:	66°
Seat Height:	830 mm / 32.7 in
Wheelbase:	1357 mm / 53.4 in
Ground Clearance:	185 mm / 7.3 in
Dry Weight:	149 kg / 328 lbs
Fuel Capacity:	13.4 L / 3.5 US gal / 2.9 Imp gal
