KTM 390 Adventure (2022) technical specifications
KTM 390 Adventure is produced in 2022. Engine is Four stroke, single cylinder, DOHC with finger followers, 4 valves, displacement 373 cc / 22.7 cu-in , produces power 43.5 hp / 32 kW @ 9500 rpm and 37 Nm / 27.2 lb-ft@ 7000rpm. KTM 390 Adventure weighs 158 kg / 348.3 lbs. KTM 390 Adventure has 5 photos.
Technical specifications
+ Add to 'Compare list'| Model: | 390 Adventure |
| Years: | 2022 |
| Engine: | Four stroke, single cylinder, DOHC with finger followers, 4 valves |
| Capacity: | 373 cc / 22.7 cu-in |
| Bore x Stroke: | 89 x 60 mm |
| Cooling System: | Liquid Cooled |
| Compression Ratio: | 12.6:1 |
| Exhaust: | Stainless steel primary and aluminium secondary silencer |
| Induction: | Bosch EFI throttle body 38 mm |
| Emission: | Euro 5 |
| Lubrication: | Wet sump |
| EMS: | Bosch EMS with RBW |
| Battery: | 12V, 8 Ah |
| Starting: | Electric |
| Max Power: | 43.5 hp / 32 kW @ 9500 rpm |
| Max Torque: | 37 Nm / 27.2 lb-ft@ 7000rpm |
| Clutch: | PASC antihopping clutch, mechanically operated |
| Traction control: | MTC |
| Transmission: | 6 Speed |
| Primary Drive Ratio: | 30:80 |
| Final Drive Ratio: | 15:45 |
| Final Drive: | Chain X-Ring 520 |
| Frame: | Steel trellis frame, powder coated, Subframe Steel trellis frame, powder coated |
| Handlebar: | Aluminium, tapered, Ø 26 / 22 mm |
| Front Suspension: | 43 mm WP APEX inverted fork |
| Front Wheel Travel: | 170 mm / 6.7 in |
| Rear Suspension: | WP APEX shock absorber, adjustbable rebound and spring preload |
| Rear Wheel Travel: | 177 mm / 7.0 in |
| Front Brakes: | Single 320 mm disc, 4 piston, radially mounted caliper |
| Rear Brakes: | Single 230 mm disc 2 piston caliper |
| ABS: | Bosch 9.1MP Two Channel-ABS (incl. Cornering-ABS and offroad mode) |
| Front Wheel: | Cast aluminium wheels 2.50 x 19 |
| Rear Wheel: | Cast aluminium wheels 3.50 x 17 |
| Front Tyre: | 100/90 ZR 19 |
| Rear Tyre: | 130/80 ZR 17 |
| Steering Head Angle: | 63.5° |
| Trail: | 98 mm / 3.8 in |
| Wheelbase: | 1430 ± 15.5 mm / 56.3 in ± 0.6 in |
| Seat Height: | 855 mm / 33.6 in |
| Ground Clearance: | 200 mm / 7.8 in |
| Dry Weight: | 158 kg / 348.3 lbs |
| Fuel Capacity: | 14.5 Litres / 3.8 US gal |
John Osborne
2024.07.22 05:39
Appearance
4
Comfort
4
Performance
4
Durability
5
Maintcost
5
Really good bike, on today's roads it is probably one of the best bikes. Light, handles very well, very light on fuel, comfortable for 5 foot 9ish.
