Technical specifications
|
| Model: |
250 EXC-E |
| Years: |
2012- |
|
Engine:
|
Two stroke, single cylinder
|
|
Capacity:
|
249 cc / 15.2 cu in
|
|
Bore x Stroke:
|
66.4 x 72.0 mm
|
|
Compression Ratio:
|
12.8:1
|
|
Cooling System:
|
Liquid cooled
|
|
Lubrication:
|
Pessure circulation lubrication with 2 rotor pumps
|
|
Induction:
|
Keihin MX FCR 39 carburetor
|
|
Ignition:
|
Contactless DC-CDI ignition with digital advanced system by KOKUSAN
|
|
Starting:
|
Kick and electric
|
|
Clutch:
|
Wet, multiplate, hydraulically operated
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain, 5/8 x 1/4 in
|
|
Primary Drive Ratio:
|
22:68
|
|
Gear Ratios:
|
1st 13:33 / 2nd 17:33 / 3rd 19:29 / 4th 23:28 / 5th 23:23 / 6th 26:22
|
|
Final Drive Ratio:
|
13:52
|
|
Frame:
|
Central chrome-moly-steel frame
|
|
Front Suspension:
|
WP Suspension – 4860 MXMA / MXMA + PA
|
|
Front Wheel Travel:
|
300 mm / 11.8 in
|
|
Rear Suspension:
|
WP Suspension – 5018 PDS MCC / DCC, aluminium swing arm
|
|
Rear Wheel Travel:
|
335 mm / 13.2 in
|
|
Front Brakes:
|
Single 260 mm disc, floating caliper
|
|
Rear Brakes:
|
Single 220 mm disc, floating caliper
|
|
Front Tyre:
|
90/90 - 21
|
|
Rear Tyre:
|
120/80 - 18
|
|
Steering Head Angle:
|
63.5°
|
|
Rake:
|
26.5°
|
|
Trail:
|
112 mm / 4.1 in
|
|
Wheelbase:
|
1475 mm / 58.1 in
|
|
Seat Height:
|
925 mm / 36.4 in
|
|
Ground Clearance:
|
380 mm / 15.1 in
|
|
Dry Weight:
|
103 kg / 227 lbs
|
|
Fuel Capacity:
|
9.5 Litres / 2.5 US gal
|
