Technical specifications
|
| Model: |
125 Duke |
| Years: |
2024 |
|
Engine:
|
Four stroke, single cylinder, DOHC, 4 valves
|
|
Capacity:
|
124.9 cc / 7.6 cu-in
|
|
Bore x Stroke:
|
58 x 47.3 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
|
|
Lubrication:
|
Wet sump
|
|
Induction:
|
Bosch electronic fuel injection
|
|
Emission:
|
EURO5
|
|
EMS:
|
Bosch EMS with RBW
|
|
Starting:
|
Electric
|
|
Max Power:
|
11 kW / 15 hp
|
|
Max Torque:
|
11.5 Nm / 8.85 ft-lb
|
|
Clutch:
|
PASC™ antihopping clutch, mechanically operated
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain 520 X-ring
|
|
Frame:
|
Steel trellis frame, powder coated
|
|
Front Suspension:
|
43 mm WP APEX
|
|
Front Wheel Travel:
|
150 mm / 5.9 in
|
|
Rear Suspension:
|
WP APEX - Monoshock
|
|
Rear Wheel Travel:
|
150 mm / 5.9 in
|
|
Front Brakes:
|
Single 320 mm disc, 4 piston radial fixed caliper
|
|
Rear Brakes:
|
Single 240 mm disc, 2 piston floating caliper
|
|
ABS:
|
Cornering ABS
|
|
Front Tyre:
|
|
|
Rear Tyre:
|
|
|
Steering Head Angle:
|
|
|
Wheelbase:
|
|
|
Ground Clearance:
|
|
|
Seat Height:
|
800 mm / 32.7 in
|
|
Dry Weight:
|
154 kg / 306.4 lbs
|
|
Fuel Capacity:
|
|
