Technical specifications
|
| Model: |
125 Duke |
| Years: |
2019-20 |
|
Engine:
|
Four stroke, single cylinder, DOHC, 4 valves
|
|
Capacity:
|
124.7 cc / 7.6 cu-in
|
|
Bore x Stroke:
|
58 x 47.2 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
14.5:1
|
|
Lubrication:
|
Wet sump
|
|
Induction:
|
Bosch electronic fuel injection
|
|
Emission:
|
EURO5
|
|
Ignition:
|
Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment
|
|
Starting:
|
Electric
|
|
Max Power:
|
11.3 kW / 15 hp @ 10500 rpm
|
|
Max Torque:
|
12 Nm / 8.85 ft-lb @ 8000 rpm
|
|
Clutch:
|
Wet multi-disc, mechanically actuated
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain 520 X-ring
|
|
Frame:
|
Steel trellis frame, powder coated
|
|
Front Suspension:
|
43 mm WP-USD, AER 43
|
|
Front Wheel Travel:
|
140 mm / 5.5 in
|
|
Rear Suspension:
|
WP Monoshock
|
|
Rear Wheel Travel:
|
162 mm / 6.4 in
|
|
Front Brakes:
|
Single 300 mm disc, 4 piston radial fixed caliper
|
|
Rear Brakes:
|
Single 230 mm disc, single piston floating caliper
|
|
ABS:
|
Bosch 10 ML Single Channel ABS
|
|
Front Tyre:
|
110/70 -17
|
|
Rear Tyre:
|
150/60 -17
|
|
Steering Head Angle:
|
65°
|
|
Wheelbase:
|
1357 mm / 53.4 in
|
|
Ground Clearance:
|
155 mm / 6.1 in
|
|
Seat Height:
|
818 mm / 32.2 in
|
|
Dry Weight:
|
141.4 kg / 311.7 lbs
|
|
Fuel Capacity:
|
11 Litres / 3.0 US gal
|
