KTM 1200 Super Adventure S (2019-20) technical specifications

KTM 1200 Super Adventure S is produced in 2019-20. Engine is Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder, displacement 1301 cc / 79.3 cu-in , produces power 118 kW / 160 hp @ 8750 rpm and 140 Nm / 103.7 lb-ft @ 6750rpm. KTM 1200 Super Adventure S weighs 215 kg / 473.9 lbs. KTM 1200 Super Adventure S has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	1200 Super Adventure S
Years:	2019-20
Engine:	Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder
Capacity:	1301 cc / 79.3 cu-in
Bore x Stroke:	108 x 71 mm
Cooling System:	Liquid cooling system, continuous circulation of cooling liquid with water pump
Valve Insp. Interval:	18,600 miles
Compression Ratio:	13.1:1
Lubrication:	Forced oil lubrication with 3 oil pumps
Induction:	2x Keihin EFI, 52mm throttle bodies
EMS:	Keihin EMS with RBW and cruise control, double ignition
Ignition:	System contactless, controlled, fully electronic ignition system with digital ignition timing adjustment
Battery:	Battery: 12V 11.2AH
Charging Output:	450 watts max.
Starting:	Eletric
Max Power:	118 kW / 160 hp @ 8750 rpm
Max Torque:	140 Nm / 103.7 lb-ft @ 6750rpm
Clutch:	PASC™ anti-hopping clutch/ hydraulically operated
Transmission:	6-speed
Final Drive:	Chain 5/8 x 5/16" X Ring
Primary Gear Ratio:	40:76
Frame:	Tubular space frame made from chrome molybdenum steel, powder-coated
Front Suspension:	WP Semi-active Suspension USD Ø 48 mm
Front Wheel Travel:	200 mm / 7.9 in
Rear Suspension:	Shock absorber WP Semi-active Suspension PDS Monoshock
Rear Wheel Travel:	200 mm / 7.9 in
Front Brakes:	2 x 320 mm floating disc, Brembo four-piston brake calipers
Rear Brakes:	Single 267 mm disc, Brembo two-piston brake caliper
ABS:	Bosch 9ME combined ABS, incl. cornering ABS and offroad mode, disengageable
Front Tyre:	120/70-ZR19
Rear Tyre:	170/60-ZR17
Steering Head Angle:	64°
Wheelbase:	1560±15 mm / 61.4 in
Seat Height:	860 mm / 33.5 in
Ground Clearance:	220 mm / 8.7 in
Dry Weight:	215 kg / 473.9 lbs
Fuel Capacity:	23 Litres / 6 US gal
