KTM 1200 Super Adventure R (2019-20) technical specifications
KTM 1200 Super Adventure R is produced in 2019-20. Engine is Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder, displacement 1301 cc / 79.3 cu-in , produces power 118 kW / 160 hp @ 8750 rpm and 140 Nm / 103.7 lb-ft @ 6750rpm. KTM 1200 Super Adventure R weighs 217 kg / 478.4 lbs. KTM 1200 Super Adventure R has 3 photos.
Technical specifications
+ Add to 'Compare list'Model: | 1200 Super Adventure R |
Years: | 2019-20 |
Engine: | Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder |
Capacity: | 1301 cc / 79.3 cu-in |
Bore x Stroke: | 108 x 71 mm |
Cooling System: | Liquid cooling system, continuous circulation of cooling liquid with water pump |
Valve Insp. Interval: | 18,600 miles |
Compression Ratio: | 13.1:1 |
Lubrication: | Forced oil lubrication with 3 oil pumps |
Induction: | 2x Keihin EFI w/ 52mm throttle bodies |
EMS: | Keihin EMS with RBW and cruise control, double ignition |
Ignition: | System contactless, controlled, fully electronic ignition system with digital ignition timing adjustment |
Battery: | Battery: 12V 11.2AH |
Charging Output: | 450 watts max. |
Starting: | Eletric |
Max Power: | 118 kW / 160 hp @ 8750 rpm |
Max Torque: | 140 Nm / 103.7 lb-ft @ 6750rpm |
Clutch: | PASC™ anti-hopping clutch/ hydraulically operated |
Transmission: | 6-speed |
Final Drive: | Chain 5/8 x 5/16" X Ring |
Primary Gear Ratio: | 40:76 |
Frame: | Tubular space frame made from chrome molybdenum steel, powder-coated |
Front Suspension: | WP Semi-active Suspension USD Ø 48 mm |
Front Wheel Travel: | 220 mm / 8.6 in |
Rear Suspension: | Shock absorber WP Semi-active Suspension PDS Monoshock |
Rear Wheel Travel: | 220 mm / 8.6 in |
Front Brakes: | 2 x 320 mm floating disc, Brembo four-piston brake calipers |
Rear Brakes: | Single 267 mm disc, Brembo two-piston brake caliper |
ABS: | Bosch 9ME combined ABS, incl. cornering ABS and offroad mode, disengageable |
Front Wheel: | Spoked aluminum |
Rear Wheel: | Spoked aluminum |
Front Tyre: | 90/90-21 |
Rear Tyre: | 150/70-ZR18 |
Steering Head Angle: | 64° |
Wheelbase: | 1580±15 mm / 62.2 in |
Seat Height: | 890 mm / 35 in |
Ground Clearance: | 250 mm / 9.8 in |
Dry Weight: | 217 kg / 478.4 lbs |
Fuel Capacity: | 23 Litres / 6 US gal |
