KTM 1190 Adventure R (2016) technical specifications

KTM 1190 Adventure R is produced in 2016. Engine is Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder, displacement 1195 cc / 72.9 cu-in , produces power 147.5 hp / 107.7 kW @ 9500 rpm and 92.2 lb-ft / 124.8 Nm @ 7500 rpm. KTM 1190 Adventure R weighs 217 kg / 478.4 lb. KTM 1190 Adventure R has 5 photos.

Technical specifications

+ Add to 'Compare list'

Model:	1190 Adventure R
Years:	2016
Engine:	Four stroke, 75°V-twin cylinder, DOHC, 4 valves per cylinder
Capacity:	1195 cc / 72.9 cu-in
Bore x Stroke:	105 x 69 mm
Cooling System:	Liquid cooling
Compression Ratio:	12.5:1
Lubrication:	Forced oil lubrication with 3 rotor pumps
Induction:	EFI, ride by wire
Ignition:	Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment
Starting:	Electric
Max Power:	147.5 hp / 107.7 kW @ 9500 rpm
Max Torque:	92.2 lb-ft / 124.8 Nm @ 7500 rpm
Clutch:	Wet multi-disc clutch, hydraulically operated
Transmission:	6 Speed
Final Drive:	Chain 5/8 x 5/16" X Ring
Primary gear ratio:	40:76
Secondary gear ratio:	17:42
Frame:	Tubular space frame made from chrome molybdenum steel, powder-coated
Front Suspension:	48mm WP USD forks
Front Wheel Travel:	220 mm / 8.6 in
Rear Suspension:	WP-PDS rear shock, hydraulic spring preload.
Rear Wheel Travel:	220 mm / 8.6 in
Front Brakes:	2x 320mm discs 4 piston calipers
Rear Brakes:	Single 267mm disc 2 piston caliper
Front Tyre:	90 / 90 ZR21
Rear Tyre:	150/60 ZR18
Steering Head Angle:	64°
Rake:	26.0°
Trail:	129.5 mm / 5.1 in.
Wheelbase:	1580 mm / 62.2 in
Seat Height:	890 mm / 35 in
Ground Clearance:	250 mm / 9.8 in (unloaded)
Dry Weight:	217 kg / 478.4 lb
Fuel Capacity:	23 Litres / 6.08 gal
