Kawasaki ZX-R 750-L (1993) technical specifications

Kawasaki ZX-R 750-L is produced in 1993. Engine is Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder., displacement 749 cc / 45.7 cu-in , produces power 118 hp / 86 kW @ 10500 rpm and 7.51 kgf-m / 54.3 lb-ft @ 9750 rpm. Kawasaki ZX-R 750-L top speed is 258.1 km/h / 160.3 mph. Kawasaki ZX-R 750-L weighs 205 kg / 451.9 lbs. Kawasaki ZX-R 750-L has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	ZX-R 750-L
Years:	1993
Engine:	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.
Capacity:	749 cc / 45.7 cu-in
Bore x Stroke:	71 x 47.3 mm
Cooling System:	Liquid cooled
Compression Ratio:	10.8:1
Lubrication:	Wet sump
Engine Oil:	10W/40
Induction:	4x 38 mm Keihin CVKD (Constant Velocity) carburettors / Ram Air System (single intake)
Ignition:	Digital
Spark Plug:	NGK, CR9E
Starting:	Electric
Max Power:	118 hp / 86 kW @ 10500 rpm
Max Torque:	7.51 kgf-m / 54.3 lb-ft @ 9750 rpm
Clutch:	Multi plate wet (oil submerged) hydraulic ‘slipper’ clutch
Transmission:	6 Speed
Final Drive:	Chain
Frame:	Aluminium perimeter
Front Suspension:	41mm Upside-down forks, adjustable ride height, 13-way rebound
Front Wheel Travel:	120 mm / 4.7 in
Rear Suspension:	Unit Track monoshock. adjustable ride height, preload, 4-way rebound
Rear Wheel Travel:	135 mm / 5.1 in
Front Brakes:	2x 320mm discs 4 piston calipers
Rear Brakes:	Single 230mm disc 2 piston caliper
Front Tyre:	120/70 ZR17
Rear Tyre:	180/55ZR17 /Std Pressure 41psi
Rake:	25°
Trail:	99 mm / 4.0 in
Wheelbase:	1430 mm / 55.9 in
Dry Weight:	205 kg / 451.9 lbs
Wet Weight:	221.6 kg / 487.2 lbs
Fuel Capacity:	18 Litres / 4.7 US gal
Consumption Average:	16.3 km/lit
Braking 60 - 0 / 100 - 0:	13.8 m / 38.1 m
Standing ¼ Mile:	10.7 sec / 207.2 km/h
Top Speed:	258.1 km/h / 160.3 mph
Road Test:	Motociclismo 1989 Motosprint Group Test 1993
