Kawasaki ZX-6R Ninja Homologation Special Edition (2013) technical specifications
Kawasaki ZX-6R Ninja Homologation Special Edition is produced in 2013. Engine is Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder, displacement 599 cc / 36.6 cub in , produces power 94.1 kW / 128 hp @ 14000 rpm and 66.7 Nm / 6.8 kgf-m / 49.2 lb-ft @ 11800 rpm. Kawasaki ZX-6R Ninja Homologation Special Edition wet weight is 191 kg / 421 lb. Kawasaki ZX-6R Ninja Homologation Special Edition has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | ZX-6R Ninja Homologation Special Edition |
| Years: | 2013 |
| Engine: | Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder |
| Capacity: | 599 cc / 36.6 cub in |
| Bore x Stroke: | 67 x 42.5mm |
| Compression Ratio: | 13.3:1 |
| Cooling System: | Liquid cooled |
| Induction: | DFI® with four 38mm Keihin throttle bodies, oval sub-throttles, two injectors per throttle body |
| Ignition: | TCBI with digital advance |
| Starting: | Electric |
| Max Power: | 94.1 kW / 128 hp @ 14000 rpm |
| Max Power Ram Air: | 98.5 kW / 134 hp @ 14000 rpm |
| Max Torque: | 66.7 Nm / 6.8 kgf-m / 49.2 lb-ft @ 11800 rpm |
| Clutch: | Wet multi-disc, manual |
| Transmission: | 6 Speed |
| Final Drive: | Sealed Chain |
| Gear Ratios: | 1st 2.714 (38/14) 2nd 2.200 (33/15) 3rd 1.850 (37/20) 4th 1.600 (32/20) 5th 1.421 (27/19) 6th 1.300 (26/20) Final reduction ratio 2.688 (43/16) |
| Primary Reduction Ratio: | 1.900 (76/40) |
| Frame: | Aluminum perimeter, Rake / trail: 24 deg / 4.0 in. |
| Front Suspension: | 41 mm inverted Showa Big Piston Front fork with top-out springs, stepless compression and rebound damping, fully-adjustable spring preload, |
| Front Wheel Travel: | 120 mm / 4.7 in |
| Rear Suspension: | Bottom-Link Uni-Trak® with gas-charged shock, top-out spring and pillow ball upper mount, dual-range (high/low-speed) stepless compression damping, 25-way adjustable rebound damping, fully-adjustable spring preload |
| Rear Wheel Travel: | 134 mm / 5.2 in. |
| Front Brakes: | 2 x 300mm discs, 4 piston calipers |
| Rear Brakes: | Single 220mm disc, 1 piston caliper |
| Front Tyre: | 120/70 ZR17 |
| Rear Tyre: | 180/55 ZR17 |
| Rake: | 23.5° |
| Trail: | 103 mm / 4.0 in. |
| Dimensions: | Length 2090 mm / 82.3 in Width 705 mm / 28.0 in Height 1115 mm /43.9 in |
| Wheelbase: | 1400 mm / 5.1 in |
| Ground Clearance: | 120 mm / 4.72 in |
| Seat Height: | 815 mm / 32.3 in. |
| Wet Weight: | 191 kg / 421 lb |
| Fuel Capacity: | 17 Litres / 4.5 US gal |
