Kawasaki ZN 700 LTD (1984) technical specifications
Kawasaki ZN 700 LTD is produced in 1984. Engine is Four stroke, inline four, 2 valves per cylinder, DOHC, displacement 694 cc / 42.4 cu in , produces power 54 kW / 74 hp @ 9500 rpm. Kawasaki ZN 700 LTD weighs 217 kg / 478 lbs. Kawasaki ZN 700 LTD has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | ZN 700 LTD |
| Years: | 1984 |
| Engine: | Four stroke, inline four, 2 valves per cylinder, DOHC |
| Capacity: | 694 cc / 42.4 cu in |
| Bore x Stroke: | 64 x 54 mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 9.7:1 |
| Lubrication: | Wet sump |
| Exhaust: | Dual stainless steel megaphone pipes |
| Induction: | Kehin CV34 x 4 carburetors |
| Ignition: | CDI |
| Starting: | Electric |
| Max Power: | 54 kW / 74 hp @ 9500 rpm |
| Clutch: | Wet, multiplate |
| Transmission: | 5-Speed |
| Final Drive: | Shaft |
| Frame: | Tubular, double cradle |
| Front Suspension: | Telescopic fork |
| Front Wheel Travel: | 160 mm / 6.3" |
| Rear Suspension: | Swingarm with dual air adjustable shocks |
| Rear Wheel Travel: | 100 mm / 3.9" |
| Front Brakes: | Single disc, single piston caliper |
| Rear Brakes: | Single disc |
| Front Tyre: | 110/90-18 61H |
| Rear Tyre: | 130/90-16 67H |
| Rake: | 29.8° |
| Trail: | 112 mm / 4.4 in |
| Dimensions: | Length 2220 mm / 87.4 in Width 830 mm / 32.3 in Height 1210 mm / 47.6 in |
| Wheelbase: | 1510 mm / 59.4 in |
| Ground Clearance: | 150 mm / 5.9 in |
| Dry Weight: | 217 kg / 478 lbs |
| Fuel Capacity: | 13.9 L / 3.7 US gal |
