Technical specifications
|
| Model: |
Z125 |
| Years: |
2022 |
|
Engine:
|
Four stroke, single cylinder, SOHC, 2 valve
|
|
Capacity:
|
125 cc / 7.6 cu in
|
|
Bore x Stroke:
|
56 x 50.6 mm
|
|
Compression Ratio:
|
9.8:1
|
|
Cooling System:
|
Air cooled
|
|
Lubrication:
|
Forced lubrication, wet sump
|
|
Induction:
|
Fuel injection: ø24 mm x 1
|
|
Ignition:
|
Digital
|
|
Starting:
|
Electric
|
|
Max Power:
|
7.1 kW / 9.5 hp @ 8000 rpm
|
|
Max Torque:
|
6 Nm / 4.4 lb-ft @ 6000 rpm
|
|
Clutch:
|
Wet multi-disc, manual
|
|
Transmission:
|
4 Speed
|
|
Final Drive:
|
Chain
|
|
Gear Tatio:
|
1st 3.000 (36/12) 2nd 1.938 (31/16) 3rd 1.350 (27/20) 4th 1.087 (25/23)
|
|
Frame:
|
Backbone, high-tensile steel
|
|
Front Suspension:
|
30mm Inverted fork
|
|
Front Wheel Travel:
|
100mm / 3.9 in
|
|
Rear Suspension:
|
Offset laydown single-shock with adjustable preload
|
|
Rear Wheel Travel:
|
104 mm / 4.1 in
|
|
Front Brakes:
|
Single 200mm petal disc, single piston calipers
|
|
Rear Brakes:
|
Single 185mm petal disc, single piston calipers
|
|
Front Tyre:
|
100/90-12 49J
|
|
Rear Tyre:
|
120/70-12 51L
|
|
Rake:
|
26.0°
|
|
Trail:
|
69 mm / 1.8 US gfal
|
|
Dimensions:
|
Length 1700 mm / 67 in width 750mm / 29.5 in Height 1005 mm / 39.5 in
|
|
Wheelbase:
|
1175 mm / 46.3 in
|
|
Seat Height:
|
855 mm / 31.7 in
|
|
Ground Clearance:
|
155 mm / 6.1 in
|
|
Wet Weight:
|
102 kg / 225 lbs
|
|
Fuel Capacity:
|
7.4 Litres / 2.0 US gal
|
