Kawasaki Z-X10R Ninja (2016) technical specifications

Kawasaki Z-X10R Ninja is produced in 2016. Engine is Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder., displacement 998 cc / 60.9 cu-in , produces power 146 kW / 200 hp @ 13000 rpm and 113.5 Nm / 83.7 lb-ft @ 11600 rpm. Kawasaki Z-X10R Ninja wet weight is 204 kg / 449.8 lbs ABS 206 kg / 454.2 lbs. Kawasaki Z-X10R Ninja has 10 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Z-X10R Ninja
Years:	2016
Engine:	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.
Capacity:	998 cc / 60.9 cu-in
Bore x Stroke:	76 x 55 mm
Compression Ratio:	13.0:1
Cooling System:	Liquid cooled
Lubrication:	Forced lubrication, wet sump with oil cooler
Induction:	DFI® with four 47mm Keihin throttle bodies, two injectors per cylinder
Ignition:	TCBI with digital advance and Sport-Kawasaki Traction Control (S-KTRC)
Starting:	Electric
Max Power:	146 kW / 200 hp @ 13000 rpm
Max Power Ram Air:	154.5 kW / 210 hp @ 13000 rpm
Max Torque:	113.5 Nm / 83.7 lb-ft @ 11600 rpm
Electronic Rider Aids:	Kawasaki Launch Control Mode (KLCM), Sport Kawasaki TRaction Control (S-KTRC), Kawasaki Engine Braking Control, Electronic Throttle Valve (ETV) and Kawasaki Quick Shifter (KQS)
Clutch:	Wet multi-disc, manual
Transmission:	6 Speed
Final Drive:	Sealed Chain
Primary Reduction Ratio:	1.556 (84/54)
Gear Ratio:	1st 2.611(47/18) 2nd 1.947 (37/19) 3rd 1.545 (34/22) 4th 1.333 (32/24) 5th 1.154 (30/26) 6th 1.036 (29/28)
Final Reduction Ratio:	2.471 (42/17)
Frame:	Aluminum perimeter
Front Suspension:	43mm inverted Showa Balance Free Fork, adjustable stepless rebound and compression damping, spring preload adjustability
Front Wheel Travel:	120 mm / 4.7 in
Rear Suspension:	Horizontal back-link with gas-charged shock, stepless, dual-range (low/high-speed) compression damping, stepless rebound damping, fully adjustable spring preload
Rear Wheel Travel:	114.5 mm / 4.5 in
Front Brakes:	2x 330 mm floating discs, dual radial-mounted 4-piston callipers
Rear Brakes:	Single 220mm disc with aluminum single-piston caliper
Front Tyre:	120/70 ZR17
Rear Tyre:	190/55 ZR17
Rake:	25°
Trail:	106.68 mm / 4.2 in
Dimensions:	Length 2090 mm / 82.3 in Width 739 mm / 29.1 in Height 1145 mm / 45.1 in
Wheelbase:	1440 mm / 56.7 in
Ground Clearance:	144 mm / 5.7 in
Seat Height:	835 mm / 32.9 in
Wet Weight:	204 kg / 449.8 lbs ABS 206 kg / 454.2 lbs
Fuel Capacity:	17 Litres / 4.5 gal
