Kawasaki Z H2 (2020) technical specifications

Kawasaki Z H2 is produced in 2020. Engine is Four Stroke, transverse four cylinder, DOHC, 16 valve, Supercharger Centrifugal, scroll-type, displacement 998 cc / 60.9 cub in , produces power 197 hp / 147 kW @ 11000rpm and 137 Nm / 101 lb-ft @ 8500 rpm. Kawasaki Z H2 wet weight is 239 kg / 527 lbs. Kawasaki Z H2 has 9 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Z H2
Years:	2020
Engine:	Four Stroke, transverse four cylinder, DOHC, 16 valve, Supercharger Centrifugal, scroll-type
Capacity:	998 cc / 60.9 cub in
Bore x Stroke:	76 x 55 mm
Cooling System:	Liquid cooled
Compression Ratio:	11.2:1
Lubrication:	Forced, wet sump with oil cooler
Exhaust:	4-1-2
Induction:	Fuel-injected with supercharger
Ignition:	Digital
Starting:	Electric
Max Power:	197 hp / 147 kW @ 11000rpm
Max Torque:	137 Nm / 101 lb-ft @ 8500 rpm
Transmission:	6-speed, return, dog-ring
Final Drive:	Chain
Primary Reduction Ratio:	1.480 (74/50)
Gear Ratios:	1st 3.077 2nd 2.471 3rd 2.045 4th 1.727 5th 1.524 6th 1.348
Final Drive Ratio:	46/18
Frame:	Trellis, high-tensile steel
Front Suspension:	Showa SSF BP forks
Front Wheel Travel:	120 mm / 4.7 in
Rear Suspension:	Showa shock - Uni Trak
Rear Wheel Travel:	134 mm / 5.2 in
Front Brakes:	2x 290mm discs, Brembo M4 monobloc calipers
Rear Brakes:	Single 226mm disc, 2-piston caliper
Front Tyre:	120/70ZR17 M/C 58W
Rear Tyre:	190/55ZR17 M/C 75W
Rake:	24.9°
Trail:	104 mm / 4.1 in
Dimensions:	Length 2085 mm / 82 in Width 810 mm / 31.9 in Height 1130 mm / 44.4 in
Wheelbase:	1455 mm / 57.3 in
Ground Clearance:	140 mm / 5.5 in
Seat Height:	830 mm / 32.6 in
Wet Weight:	239 kg / 527 lbs
Fuel Capacity:	19 Litres / 5 US gal
