Technical specifications
|
| Model: |
Z 1000 Z1R |
| Years: |
1978-79 |
|
Engine:
|
Four stroke, transverse four cylinder, DOHC, 2 Valve per cylinder.
|
|
Capacity:
|
1015 cc / 61.9 cu-in
|
|
Bore x Stroke:
|
69.4 х 66 mm
|
|
Cooling System:
|
Air cooled
|
|
Compression Ratio:
|
8.7:1
|
|
Lubrication:
|
Wet sump
|
|
Induction:
|
4x Mikuni VM28SS carbs
|
|
Ignition:
|
Battery & coil ignition
|
|
Spark Plugs:
|
NGK B8ES
|
|
Battery:
|
12V 14AH YB-14L-A2.7
|
|
Starting:
|
Electric
|
|
Max Power:
|
94 hp / 70.0 kW @ 8000 rpm
|
|
Max Torque:
|
8.7 kgf-m / 62.9 lb-ft @ 7000 rpm
|
|
Clutch:
|
Wet multiplate
|
|
Transmission:
|
5 Speed
|
|
Final Drive:
|
Chain
|
|
Gear Ratio:
|
1st 3.17 (38/12) 2nd 2.19 (35/16) 3rd 1.67 (35/21) 4th 1.38 (29/21) 5th 1.22 (28/23)
|
|
Frame:
|
Double tubular steel cradle
|
|
Front Suspension:
|
36mm Telescopic hydraulics forks
|
|
Rear Suspension:
|
Dual chocks, swinging arm,
|
|
Front Brakes:
|
2x 296mm discs
|
|
Rear Brakes:
|
Single 290mm disc
|
|
Front Tyre:
|
3.50-18
|
|
Rear Tyre:
|
4.00-18
|
|
Dimensions:
|
Length 2160mm / 85.0 in Width 800mm / 31.4 in Height 1295mm / 50.9 in
|
|
Wheelbase:
|
1505 mm / 59.2 in
|
|
Seat Height:
|
815mm / 21.0 in
|
|
Ground Clearance:
|
125 mm / 4.9 in
|
|
Dry Weight:
|
246 kg / 542.3 lbs
|
|
Fuel Capacity:
|
13 Litres / 3.4 US gal
|
|
Consumption Average:
|
43 mpg
|
|
Standing ¼ Mile:
|
11.9 sec / 176 km/h
|
|
Top Speed:
|
220 km//h / 136.7 mph
|
