Technical specifications
|
| Model: |
Z 1000 |
| Years: |
2003-04 |
|
Engine:
|
Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder.
|
|
Capacity:
|
953 cc / 58.1 cu-in
|
|
Bore x Stroke:
|
77.2 x 50.9 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
11.2:1
|
|
Lubrication:
|
Wet sump
|
|
Engine Oil:
|
Synthetic, 10W/40
|
|
Induction:
|
4x 38mm throttle bodies
|
|
Ignition:
|
Digital
|
|
Spark Plug:
|
NGK, CR9EK
|
|
Starting:
|
Electric
|
|
Max Power:
|
127 hp / 92.7 kW @ 10000 rpm
|
|
Max Torque:
|
95.6 Nm / 70.5 ft/ lbs @ 8000 rpm
|
|
Clutch:
|
Wet, multiple discs, cable operated
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain
|
|
Frame:
|
Steel, Backbone frame
|
|
Front Suspension:
|
41mm cartridge fork, rebound, spring preload adjustable
|
|
Rear Suspension:
|
Uni-Trak, rebound spring preload adjustable
|
|
Front Brakes:
|
2x 300mm 4 piston calipers
|
|
Rear Brakes:
|
Single 292mm disc 2 piston caliper
|
|
Front Tyre:
|
120/70 R17
|
|
Rear Tyre:
|
190/50 R17
|
|
Rake:
|
25°
|
|
Trail:
|
102 mm / 4.0 in
|
|
Dimension:
|
Length 2080 mm / 81.9 in Width 770 mm / 30.3 in Height 1055 mm / 41.5 in
|
|
Wheelbase:
|
1420 mm / 55.9 in
|
|
Seat Height:
|
820 mm / 32.3 in
|
|
Ground Clearance:
|
145 mm / 5.7 in
|
|
Dry Weight:
|
198 kg / 436.5 lbs
|
|
Wet Weight:
|
221 kg / 487.2 lbs
|
|
Fuel Capacity:
|
18 Litres / 4.8 US gal
|
|
Consumption Average:
|
18.9 km/lit
|
|
Standing ¼ Mile:
|
11.3 sec / 122 mph
|
|
Top Speed:
|
238 km/h / 148 mph
|
