Kawasaki VN 1700 Vulcan Voyager (2013-14) technical specifications

Kawasaki VN 1700 Vulcan Voyager is produced in 2013-14. Engine is Four stroke, V-twin cylinder, SOHC, 8 valve per cylinder, displacement 1700 cc / 103.7 cu in , produces power 61 kW / 82 hp @ 5000 rpm and 146 Nm / 107 lb-ft @ 2750 rpm. Kawasaki VN 1700 Vulcan Voyager weighs 402 kg / 886 lbs. Kawasaki VN 1700 Vulcan Voyager has 5 photos.

Technical specifications

+ Add to 'Compare list'

Model:	VN 1700 Vulcan Voyager
Years:	2013-14
Engine:	Four stroke, V-twin cylinder, SOHC, 8 valve per cylinder
Capacity:	1700 cc / 103.7 cu in
Bore x Stroke:	102 x 104mm
Cooling System:	Liquid cooled
Compression Ratio:	9.5:1
Induction:	Digital fuel injection, dual 42mm throttle bodies
Ignition:	Digital
Starting:	Electric
Max Power:	61 kW / 82 hp @ 5000 rpm
Max Torque:	146 Nm / 107 lb-ft @ 2750 rpm
Transmission:	6 Speed with overdrive
Final Drive:	Carbon fiber belt
Gear Ratio:	1st 3.077 (40/13) 2nd 1.900 (38/20) 3rd 1.407 (38/27) 4th 1.143 (32/28) 5th 0.967 (29/30) 6th 0.806 (29/36)
Frame:	Steel, double-cradle with box-section single-tube backbone
Front Suspension:	43mm hydraulic fork
Front Wheel Travel:	140 mm / 5.5 in
Rear Suspension:	Swingarm with twin air-assisted shocks, with 4-way rebound damping
Rear Wheel Travel:	78 mm / 3.1 in
Front Brakes:	2x 300mm discs 2 piston calipers / ABS Optimal
Rear Brakes:	Single 300mm disc 2 piston caliper / ABS Optimal
Front Tyre:	130/90R16
Rear Tyre:	170/70R16
Dimensions:	Length 2,560 mm / 100.8 in Width 995 mm / 39.2 in Height 1,550 mm / 61.0 in
Wheelbase:	1665 mm / 65.6 in.
Ground clearance:	135 mm / 5.3 in
Seat Height:	730 mm / 28.7 in
Dry Weight:	402 kg / 886 lbs
Fuel Capacity:	20 Litres / 5.3 US gal
