Kawasaki VN 1700 Vulcan Nomad (2013-14) technical specifications

Kawasaki VN 1700 Vulcan Nomad is produced in 2013-14. Engine is Four stroke, V-twin, SOHC, 4 valve per cylinder, displacement 1700 cc / 103.7 in , produces power 55 kW / 74 hp @ 5000 rpm and 135 Nm / 13.7 kgf-m / 99.6 lb-ft @2750 rpm. Kawasaki VN 1700 Vulcan Nomad wet weight is 373 kg / 34 lb. Kawasaki VN 1700 Vulcan Nomad has 9 photos.

Technical specifications

+ Add to 'Compare list'

Model:	VN 1700 Vulcan Nomad
Years:	2013-14
Engine:	Four stroke, V-twin, SOHC, 4 valve per cylinder
Capacity:	1700 cc / 103.7 in
Bore x Stroke:	102 x 104 mm
Cooling System:	Liquid cooled, plus cooling fins
Compression Ratio:	9.5:1
Lubrication:	Forced lubrication, semi-dry sump
Exhaust:	Twin, stacked
Induction:	Electronic fuel injection, 42 mm dia. x 2
Ignition:	TCDI with digital advance
Starting:	Electric
Max Power:	55 kW / 74 hp @ 5000 rpm
Max Torque:	135 Nm / 13.7 kgf-m / 99.6 lb-ft @2750 rpm
Clutch:	Wet, multi-disc, manual, electronic cruise control
Transmission:	6 Speed
Final Drive:	Belt drive
Gear Ratio:	1st 3.077 (40/13) 2nd 1.900 (38/20) 3rd 1.407 (38/27) 4th 1.143 (32/28) 5th 0.967 (29/30) 6th 0.806 (29/36)
Frame:	Double cradle, steel with box section single-tube backbone
Front Suspension:	43 mm Telescopic fork
Front Wheel Travel:	140 mm / 5.5 in
Rear Suspension:	Swingarm with twin air-assisted 4 way adjustable shocks for rebound and damping
Rear Wheel Travel:	80 mm / 3.2 in
Front Brakes:	2x 300mm discs 2 piston calipers
Rear Brakes:	Single 300mm disc 2 piston caliper
Front Tyre:	130/90 -R16
Rear Tyre:	170/70 -R16
Rake:	30°
Trail:	178 mm / 7.0 in
Dimensions:	Length 2499 mm / 98.4 in Width 1025 mm / 40.4 in Height 1466 mm / 57.7 in
Wheelbase:	1,666 mm / 65.6 in
Seat Height:	730 mm / 28.7 in.
Ground Clearance:	140 mm / 5.5 in
Wet Weight:	373 kg / 34 lb
Fuel Capacity:	20 Litres / 5.3 US gal.
