Kawasaki VN 1700 Classic (2013-14) technical specifications
Kawasaki VN 1700 Classic is produced in 2013-14. Engine is Four stroke, V-twin, SOHC, 4 valve per cylinder, displacement 1700 cc / 103.7 in , produces power 55 kW / 74 hp @ 5000 rpm and 135 Nm / 13.7 kgf-m / 99.6 lb-ft @2750 rpm. Kawasaki VN 1700 Classic top speed is 185 km/h / 115 mph. Kawasaki VN 1700 Classic wet weight is 349 kg / 769 lbs. Kawasaki VN 1700 Classic has 2 photos.
Technical specifications
+ Add to 'Compare list'| Model: | VN 1700 Classic |
| Years: | 2013-14 |
| Engine: | Four stroke, V-twin, SOHC, 4 valve per cylinder |
| Capacity: | 1700 cc / 103.7 in |
| Bore x Stroke: | 102 x 104 mm |
| Cooling System: | Liquid cooled, plus cooling fins |
| Compression Ratio: | 9.5:1 |
| Lubrication: | Forced lubrication, semi-dry sump |
| Exhaust: | Twin, stacked |
| Induction: | Electronic fuel injection, 42 mm dia. x 2 |
| Ignition: | TCDI with digital advance |
| Starting: | Electric |
| Max Power: | 55 kW / 74 hp @ 5000 rpm |
| Max Torque: | 135 Nm / 13.7 kgf-m / 99.6 lb-ft @2750 rpm |
| Clutch: | Wet, multi-disc, manual, electronic cruise control |
| Transmission: | 6 Speed |
| Final Drive: | Belt drive |
| Gear Ratio: | 1st 3.077 / 2nd 1.900 / 3rd 1.407 / 4th 1.143 / 5th 0.967 / 6th 0.806:1 |
| Final Drive Ratio: | 2.250:1 |
| Frame: | Double cradle, steel with box section single-tube backbone |
| Front Suspension: | 43 mm Telescopic fork |
| Front Wheel Travel: | 140 mm / 5.5 in |
| Rear Suspension: | Swingarm with twin air-assisted 4 way adjustable shocks for rebound and damping |
| Rear Wheel Travel: | 80 mm / 3.2 in |
| Front Brakes: | 2 x 300 mm discs, dual twin piston calipers, ABS |
| Rear Brakes: | Single 300 mm disc, twin piston caliper, ABS |
| Wheels: | Alloy, 10 spokes |
| Front Tyre: | 130/90 B16M/C (67H) |
| Rear Tyre: | 170/70 B16M/C (75H) |
| Rake: | 30° |
| Steering Angle (left/right): | 35° / 35° |
| Trail: | 169 mm / 6.65 in |
| Dimensions: | Length 2500 mm / 98.4 in Width 1025 mm / 40.4 in Height 1155 mm / 45.5 in |
| Wheelbase: | 1665 mm / 65.6 in |
| Seat Height: | 720 mm / 28.3 mm |
| Ground Clearance: | 130 mm / 5.1 in |
| Wet Weight: | 349 kg / 769 lbs |
| Fuel Capacity: | 20 Litres / 5.3 US gal |
| Top Speed: | 185 km/h / 115 mph |
