Kawasaki VN 1500 Vulcan Nomad FI (2002-04) technical specifications
![Kawasaki VN 1500 Vulcan Nomad FI technical specifications Kawasaki VN 1500 Vulcan Nomad FI technical specifications](https://www.moto-data.net/media/kawasaki/pics/kawasaki-vn-1500-vulcan-nomad-fi-2002-2004[1].jpg)
Kawasaki VN 1500 Vulcan Nomad FI is produced in 2002-04. Engine is Four stroke, 50° V-Twin, SOHC, 4 valves per cylinder, displacement 1470 cc / 89.7 cu-in , produces power 64 hp / 46.7 kW @ 4700 rpm and 112 Nm / 82.6 lb-ft @ 3000 rpm. Kawasaki VN 1500 Vulcan Nomad FI weighs 337.0 kg / 739 lbs. Kawasaki VN 1500 Vulcan Nomad FI has 3 photos.
Technical specifications
+ Add to 'Compare list'Model: | VN 1500 Vulcan Nomad FI |
Years: | 2002-04 |
Engine: | Four stroke, 50° V-Twin, SOHC, 4 valves per cylinder |
Capacity: | 1470 cc / 89.7 cu-in |
Bore x Stroke: | 102 x 90 mm |
Cooling System: | Liquid cooled |
Compression Ratio: | 9.0:1 |
Induction: | Digital Fuel Injection with dual 36mm throttle bodies |
Ignition: | Digital |
Max Power: | 64 hp / 46.7 kW @ 4700 rpm |
Max Torque: | 112 Nm / 82.6 lb-ft @ 3000 rpm |
Transmission: | 5 Speed |
Final Drive: | Shaft |
Frame: | High-tensile steel, double cradle |
Front Suspension: | 41mm cartridge fork |
Front Wheel Travel: | 150 mm / 5.9 in |
Rear Suspension: | Dual air assisted shock absorbers with 4-way rebound damping adjustment |
Rear Wheel Travel: | 100 mm / 3.9 in |
Front Brakes: | 2x 320mm discs 6 piston calipers |
Rear Brakes: | Single 270mm disc 2 piston caliper |
Front Tyre: | 150/80R-16 |
Rear Tyre: | 150/80R-16 |
Rake: | 32.0° |
Trail: | 177 mm / 6.9 in |
Wheelbase: | 1661 mm / 65.4 in |
Seat Height: | 718 mm / 28.3 in |
Dry Weight: | 337.0 kg / 739 lbs |
Fuel Capacity: | 18.9 Litres / 5.0 US gal |
