Technical specifications
|
| Model: |
KMX 200 |
| Years: |
1987-88 |
|
Engine:
|
Two stroke, single cylinder, piston read valve induction
|
|
Capacity:
|
191 cc / 11.7 cu-in
|
|
Bore x Stroke:
|
67 x 54 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
8.0:1
|
|
Induction:
|
26mm Mikuni carburetor
|
|
Ignition:
|
CDI
|
|
Starting:
|
Kick
|
|
Max Power:
|
30.4 hp / @ 8500 rpm
|
|
Max Torque:
|
18.6 ft-lb / 13.0 lb-ft @ 7500 rpm
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain
|
|
Front Suspension:
|
Air assisted leading axle telescopic.
|
|
Rear Suspension:
|
Uni-Trak rising rate monoshock, adjustable preload.
|
|
Front Brakes:
|
Single 213mm disc
|
|
Rear Brakes:
|
Single 183mm disc
|
|
Front Tyre:
|
3.00-21
|
|
Rear Tyre:
|
4.60-17
|
|
Dry Weight:
|
100 kg / 220 lbs
|
|
Fuel Capacity:
|
9.3 Litres / 2.4 US gal
|
|
Road Test:
|
Moto Verte
|
